Construction and optional painting

Follow the Extreme Blast Mode booklet for the special wings, clear figures, effects and display stand. The kit combines PS, ABS and PE parts with PET wings and a PET beam shield. Use a correctly sized plus-head screwdriver for the stand's screw and nut, and trim any interfering plating only where the instructions direct.

The supplied color stickers, marking stickers and dry-transfer Gundam decals are different decoration types. Apply the dry transfers using the printed rubbing method. Bandai recommends water-based paint and advises against painting the ABS mechanical parts because paint can cause breakage.

The paint guide has ten mobile-suit recipes and eighteen figure recipes: seven for Shinn Asuka, six for Stella Loussier and five for Kira Yamato. It covers the small figures and the special clear display figures. Stella's purple suit blend includes Fluorescent Pink 30%. A separate panel-lining tip suggests a Gundam Marker or similar, sold separately, without specifying a color or product code.

Materials in the parts list: PS: body, weapon, special N/O/P and clear figure parts; ABS: K, L and M mechanical runners; PE: PC-130C polycaps; PET: Wings R/L and beam shield; Plated parts; One screw and one nut for the display stand.

Plus-head screwdriver for the supplied display stand screw/nut: Use a plus-head screwdriver that fits the supplied stand screw. No store product has been chosen for this stand-assembly tool. Reference only; no purchase option is selected.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

28 printed roles use 21 distinct named ingredients. 15 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body white: Aircraft Gray 75% + White 15% + Neutral Gray 10%. Candidate recipe incomplete: Aircraft Gray has no chosen store match.
2. Chest blue: Indy Blue 65% + White 25% + Cobalt Blue 10%. Candidate recipe incomplete: Indy Blue, Cobalt Blue has no chosen store match.
3. Feet red: Red 70% + White 20% + Yellow 10%.
4. Antenna yellow: Yellow 65% + White 30% + Orange 5%.
5. Chest intakes gray: Neutral Gray 90% + Black 10%.
6. Beam rifle blue-gray: Medium Blue 65% + Black 30% + Red 5%. Candidate recipe incomplete: Medium Blue has no chosen store match.
7. Long-range beam cannon light green: White 50% + Neutral Gray 25% + Green 25%.
8. Arondight light blue: White 70% + Cobalt Blue 20% + Purple 5% + Neutral Gray 5%. Candidate recipe incomplete: Cobalt Blue has no chosen store match.
9. Back mount black: Midnight Blue 100%.
10. Sensors yellow-green: Yellow Green 100%.
11. Shinn Asuka face: Flesh 100%.
12. Shinn Asuka hair dark blue: Blue 80% + Black 15% + Red 5%.
13. Shinn Asuka normal suit white: White 100%.
14. Shinn Asuka normal suit red: Russet (Azuki) 100%. Candidate recipe incomplete: Russet (Azuki) has no chosen store match.
15. Shinn Asuka normal suit yellow: Orange Yellow 100%.
16. Shinn Asuka normal suit dark gray: Midnight Blue 100%.
17. Shinn Asuka backpack gray: Aircraft Gray 90% + Black 10%. Candidate recipe incomplete: Aircraft Gray has no chosen store match.
18. Stella Loussier face: Flesh 100%.
19. Stella Loussier hair yellow: White 70% + Yellow 30%.
20. Stella Loussier normal suit purple: White 65% + Fluorescent Pink 30% + Purple 5%.
21. Stella Loussier normal suit light gray: Aircraft Gray 100%. Candidate recipe incomplete: Aircraft Gray has no chosen store match.
22. Stella Loussier normal suit dark gray: Midnight Blue 100%.
23. Stella Loussier backpack gray: Aircraft Gray 90% + Black 10%. Candidate recipe incomplete: Aircraft Gray has no chosen store match.
24. Kira Yamato face: Flesh 100%.
25. Kira Yamato hair brown: Mahogany 100%.
26. Kira Yamato normal suit blue: Indy Blue 80% + White 20%. Candidate recipe incomplete: Indy Blue has no chosen store match.
27. Kira Yamato normal suit white: White 100%.
28. Kira Yamato normal suit red: Red 80% + Pink 20%.

Named ingredients and optional store candidates

16 mapped purchase cards and 5 disabled ingredient references cover all 21 named ingredients. Mapped cards represent 16 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. Aircraft Gray. No candidate is chosen because the original does not identify a specific aircraft-gray shade.
2. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
3. Neutral Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. The descriptive Neutral Grey candidate supports a neutral-gray approximation. Its bottle may also serve generic Gray while both ingredient names remain separate. Family: AK 3rd Generation. Finish/effect: matte.
4. Indy Blue. No supported candidate is chosen for the named Indy Blue shade.
5. Cobalt Blue. No candidate is chosen. The available AK Cobalt Blue is metallic, while this ingredient calls for an ordinary blue.
6. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
7. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. Yellow is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
8. Orange. Approximate candidate: 3G Acrylic Medium Orange AK11078. Orange is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
9. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
10. Medium Blue. No candidate is chosen. The available AK Medium Blue sample is dark saturated blue, which does not support these blue-gray/gray source roles.
11. Green. Approximate candidate: 3G Acrylic Deep Green AK11142. Deep Green supplies a generic opaque green approximation, separate from the Dark Green and special named green ingredients. Family: AK 3rd Generation. Finish/effect: matte.
12. Purple. Approximate candidate: 3G Acrylic Purple AK11073. Purple is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
13. Midnight Blue. Approximate candidate: 3G Acrylic Strong Dark Blue AK11187. Strong Dark Blue has a very dark, near-black blue chart sample. It is an approximation to the Midnight Blue hue, distinct from Navy Blue; no manufacturer crosswalk is claimed. Family: AK 3rd Generation. Finish/effect: matte.
14. Yellow Green. Approximate candidate: 3G Acrylic Interior Yellow Green AK11138. Interior Yellow Green supplies a yellow-green hue approximation. No aircraft-interior standard is assigned to the source. Family: AK 3rd Generation. Finish/effect: matte.
15. Flesh. Approximate candidate: 3G Acrylic Basic Skin Tone AK11052. Basic Skin Tone supplies a generic flesh-color approximation. No measured likeness or skin tone is claimed. Family: AK 3rd Generation. Finish/effect: matte.
16. Blue. Approximate candidate: 3G Acrylic Deep Blue AK11182. Deep Blue supplies an opaque blue candidate, with untested depth and pigment strength. Family: AK 3rd Generation. Finish/effect: matte.
17. Russet (Azuki). No supported candidate is chosen for the named Russet (Azuki) shade.
18. Orange Yellow. Approximate candidate: 3G Acrylic Golden Yellow AK11041. Golden Yellow supplies a warm yellow-orange approximation, distinct from Orange and Yellow. Family: AK 3rd Generation. Finish/effect: matte.
19. Fluorescent Pink. Approximate candidate: 3G Acrylic Flourescent Magenta AK11068. Fluorescent Magenta offers a pink-magenta fluorescent approximation. The primary manufacturer identifies its fluorescent semi-transparent resin; its hue and fluorescence strength may differ. Family: AK 3rd Generation. Finish/effect: fluorescent.
20. Mahogany. Approximate candidate: 3G Acrylic Mahogany Brown AK11106. Mahogany Brown supplies a named reddish wood-brown approximation. Family: AK 3rd Generation. Finish/effect: matte.
21. Pink. Approximate candidate: 3G Acrylic Pastel Pink AK11059. Pastel Pink supplies a pale pink approximation; source pigment strength is unknown. Family: AK 3rd Generation. Finish/effect: matte.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
