1/25 2021 Ford Bronco First Edition 1343
Skip to product information
Build This Truck
Complete original paint requirements and documented options reviewed. Source scheme: First listed exterior option: Rapid Red Metallic; first listed interior option: Black; standard First Edition decals and common assembly. Original names and codes remain visible. Approximate or cross-family choices start unchecked; dried color, sheen and special effects are not certified equivalents. Tools and thinning purchases are unchecked. Each thinner applies only to its named family. Digital swatches are provisional; out-of-stock cards stay disabled. Source details retain all options, conflicts and original mixtures.
Original palette, placement, alternatives and source notes
Original paint roles and choices are listed below. Printed alternatives are options for the same role, not additional required purchases or guaranteed color matches. Approximate store options start unchecked.
- Source A: Black.
Listed in the instructions. Source finish: unspecified. Source location: 1; 2. Springs and brackets in step 7; body accessory part 95 step 12; grille 17 step 16; mirror housings 12/13 step 18; wheel fronts 100 step 23. Also first named standard interior-color option.
Store option: X-1 Black 23 ML (LARGE). Gloss candidate; source finish unspecified. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.
- Source B: Flat Black.
Listed in the instructions. Source finish: flat. Source location: 2. Detail areas of part 95 in step 12.
Store option: XF-1 Flat Black Mini. Flat black named-color candidate. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source C: Semi-Gloss Black.
Listed in the instructions. Source finish: semi-gloss. Source location: 1; 2. Chassis/floor underside 30,60,61 and structural/powertrain parts, steps 5–9; rear panel 53 step 12; spare-wheel retainer 27 step 25.
Store option: X-18 Semi Gloss Black 10 ML (MINI). Semi-gloss black named-color candidate. Candidate finish: Semi-gloss; paint type: Tamiya X/XF acrylic.
- Source D: White.
Listed in the instructions. Source finish: unspecified. Source location: 1. Optional painting of BRONCO grille letters in step 16; optional decal 8 can replace this painting.
Store option: X-2 White 10 ML (MINI). Gloss candidate; source finish unspecified. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.
- Source F: Silver.
Listed in the instructions. Source finish: metallic. Source location: 2. Gear-selector detail 45 step 1; steering wheel/detail and alternative dashboard fascia in step 3; interior-door detail step 11.
Store option: X-11 Chrome Silver 10 ML (MINI) 81511. Bright metallic silver candidate; specific metallic grain and sheen not physically verified. Candidate finish: Metallic; paint type: Tamiya X/XF acrylic.
- Source H: Aluminum.
Listed in the instructions. Source finish: metallic. Source location: 2. Powertrain underside parts 63–67 step 4; inset area of part 83 step 9.
Store option: XF-16 Flat Aluminum 10 ML (MINI). Flat aluminum metallic candidate; source sheen unspecified. Candidate finish: Matte metallic; paint type: Tamiya X/XF acrylic.
- Source I: Steel.
Listed in the instructions. Source finish: metallic. Source location: 1; 2. Exhaust 68/69 step 5, axle surfaces step 6, driveline/brake hardware 82 step 8, brake discs 87/88 step 24.
Store option: Steel (71065). Vallejo Model Air metallic steel candidate; separate water-based acrylic family. Candidate finish: Metallic; paint type: water-based acrylic.
- Source Q: Yellow.
Listed in the instructions. Source finish: unspecified. Source location: 2. Shock absorber bodies 75/76/80/81, step 7; separate from black springs.
Store option: X-8 Lemon Yellow 10 ML (MINI). Gloss lemon yellow candidate; exact hue and source finish unspecified. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.
- Source Z: Satin Black.
Listed in the instructions. Source finish: satin. Source location: 1; 2. Skid plate 86 step 10; fenders, body trim, bumpers, roof 3, wipers, mirrors/supports and spare-wheel mount, steps 14–21 and 25.
Store option: ATOM COLOR Satin Black (20162). Satin black water-based acrylic candidate; use separately from Tamiya acrylic. Candidate finish: Satin; paint type: water-based acrylic.
- Source BC1: Rapid Red Metallic.
Listed in the instructions. Source finish: metallic. Source location: 1; 2. First standard exterior color named in page 1 EXTERIOR COLORS; body 1 step 14 and hood 2 step 15 use BC.
Store option: Lacquer LP-46 Metallic Red. Explicit metallic-red candidate. Approximate store suggestion only; not a manufacturer-specified paint or verified factory-color equivalent. Does not reproduce Ford Rapid Red tintcoat layering, exact hue or flake. Candidate finish: Metallic; paint type: lacquer.
- Source BC2: Area 51.
Listed in the instructions. Source finish: unspecified. Source location: 1; 2. Second named standard exterior color, an alternative for BC.
Store option: XF-18 Medium Blue 10 ML (MINI). Unchecked hue-only approximation for Area 51: a dark, muted blue-green/blue-gray. Tamiya XF-18’s maker chip lies in the same broad hue family, but it is a flat acrylic military color, not a Ford factory match. Exact hue and automotive surface sheen are not established; no gloss-coat product or recipe is automatically added. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source BC3: Cactus Gray.
Listed in the instructions. Source finish: unspecified. Source location: 1; 2. Third named standard exterior color, an alternative for BC.
Store option: Semi-Gloss Gray Green Mr.Color 10ml C128. Unchecked light gray-green approximation for Cactus Gray. Mr. Color C128 Gray Green is a pale, low-saturation gray-green that appears lighter and less olive than the Ford color chip. Its semi-gloss finish is not an established Ford body finish. Exact hue, sheen and automotive appearance remain unverified; no mix or clear-coat recipe is specified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.
- Source BC4: Cyber Orange Metallic.
Listed in the instructions. Source finish: metallic. Source location: 1; 2. Fourth named standard exterior color, an alternative for BC.
Store option: Lacquer LP-44 Metallic Orange. Explicit metallic-orange candidate. Approximate store suggestion only; not a manufacturer-specified paint or verified factory-color equivalent. Does not recreate Ford Cyber Orange tri-coat construction or exact yellow/orange balance. Candidate finish: Metallic; paint type: lacquer.
- Source IC2: Dark Space Gray.
Listed in the instructions. Source finish: unspecified. Source location: 1; 2. Named standard interior color alternative; IC appears throughout interior, steps 1–3,5,11,13–14.
Store option: Pro Acryl Dark Neutral Grey 044. Unchecked broad dark neutral-gray candidate. Exact Ford upholstery tone and sheen remain unverified. This opaque model paint does not reproduce fabric texture. Candidate finish: Matte; paint type: water-based acrylic.
- Source IC3: Navy Pier.
Listed in the instructions. Source finish: unspecified. Source location: 1; 2. Named standard interior color alternative; IC appears throughout interior, steps 1–3,5,11,13–14.
Store option: XF-18 Medium Blue 10 ML (MINI). Unchecked broad slate/navy-blue approximation for Navy Pier. The Ford brochure’s cloth and leather swatches show a dark, subdued blue. XF-18 is a flat blue-gray acrylic and is not an exact upholstery color or texture match. Area 51 and Navy Pier remain distinct source colors even where the same broad modeling candidate is offered. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
Guide scheme
- First listed exterior option: Rapid Red Metallic; first listed interior option: Black; standard First Edition decals and common assembly
- Rapid Red Metallic body and Black interior are the first listed choices. Grille decal 8 is used instead of optional White D. These independent choices are not a separately named manufacturer scheme.
Source limitations and material guidance
- The instructions name colors without specifying a paint brand or product code. Store suggestions are approximate; their hue, sheen and texture may differ from Ford body paint or upholstery. No factory-equivalent finish or clear-coat recipe is specified.
- The general A–AA key contains unused colors. This build uses A, B, C, D, F, H, I, Q and Z, plus four body-color choices and three interior-color choices. White D is optional for the BRONCO grille letters because decal 8 can be used instead. Body and interior colors are independent choices.
- Headlamp reflectors P3/P4 and mirror faces P1/P2 are supplied plated parts. Side/rear glazing C2/C5 is supplied smoked-clear material; rear lenses R1/R2 are transparent-red material. These material descriptions do not require extra Chrome, Smoke or Transparent Red paint.
- Tires have no paint callout. Wheel fronts 100 use A Black; brake discs 87/88 use I Steel. Spare wheel 101 and the extra parts shown at step 25 add no new paint. Alternate hood and other decals add no paint colors. No mixtures or ratios are specified.
Source references
Paints (14)
0 items selected
Tools and supplies (13)
Select any tools you need to add them with your paint selection.
Checking supply availability…
Paints and supplies sold separately. Prices and availability update from each product.
