All source paint roles are retained below. Alternatives are source cross-references, not extra required purchases or certified exact matches. Printed blank values stay unspecified.

1. Source WHITE: White. Source status: applied. Source finish: unspecified. Pages 1; 2. Page1 section1 water manifold8 and two filter23 parts; page2 section10 roof air-conditioner4. Section7 mudflaps18 allow WHITE or FLAT BLACK; WHITE is the first printed option.

   Store option: X-2 White 10 ML (MINI). Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Gloss; chemistry: Tamiya X/XF acrylic.

2. Source SILVER: Silver. Source status: applied. Source finish: metallic; sheen unspecified. Pages 1; 2. Page1 section1 exhaust outlet10, exhaust turbine12, alternator15, breather21, oil filler cap22 and water outlet24; section2 front outer wheel flanges and both rear inner/outer wheel flanges list SILVER or BODY or CHASSIS COLOR; section5 taillight bezel16 and license plate17. Page2 section7 fuel-tank bodies10 and ends11; section10 exhaust pipe16.

   Store option: X-11 Chrome Silver 10 ML (MINI) 81511. Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Metallic; chemistry: Tamiya X/XF acrylic.

3. Source BLACK: Black. Source status: applied. Source finish: unspecified. Pages 1; 2. Page1 section1 transmission3, air cylinders4, starter13 and dipstick14; section2 rear brake drums. Page2 section7 main driveshaft1, fuel-tank mounts12, air tanks16/auxiliary17, battery box8/cover9 and fifth-wheel slide plate19/carriage20/fifth wheel21; section8 steering column3, instrument dials, heater4 and firewall5; section10 steering shaft10. BLACK has no sheen specified; keep separate from FLAT BLACK and GLOSS BLACK.

   Store option: X-1 Black 10 ML (MINI). Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Gloss; chemistry: Tamiya X/XF acrylic.

4. Source FLAT BLACK: Flat Black. Source status: applied. Source finish: flat. Pages 1; 2. Page1 section1 all drive belts16/17/18. Page2 section7 radiator3, surge tank4, radiator hoses5/6 and batteries7, with mudflaps18 as an alternate to WHITE; section8 driver seat support8, passenger seat base10 and all pedals; section9 window frame, assembled interior bottom and firewall; section10 intake11/filter12; section11 inside hood and the hood-hinge/detail bar.

   Store option: XF-1 Flat Black Mini. Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Matte; chemistry: Tamiya X/XF acrylic.

5. Source TAN/BEIGE: Tan/Beige. Source status: applied. Source finish: unspecified. Pages 1. Section1 all engine parts not directly labeled another color, plus the pulleys and fan19. Source prints TAN/BEIGE as a single descriptive shade choice; no two-paint mix or ratio is supplied.

   Store option: XF-55 Deck Tan 10 ML (MINI). Matte light beige/tan approximation; exact source shade and sheen are unverified. Candidate finish: Matte; chemistry: Tamiya X/XF acrylic.

6. Source GLOSS BLACK: Gloss Black. Source status: applied. Source finish: gloss. Pages 1; 2. Page1 section3 basic-chassis blanket note and section5 all suspension parts not directly labeled; page2 section6 front-axle blanket note. Also an available CHASSIS COLOR option for wheel flanges/rear wheels in section2. Retain literal blanket note and earlier specific wheel/color/chrome instructions.

   Store option: X-1 Black 10 ML (MINI). Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Gloss; chemistry: Tamiya X/XF acrylic.

7. Source BRASS: Brass. Source status: applied. Source finish: metallic; sheen unspecified. Pages 2. Section7 Hose Tenna22; its mounting location changes for the optional sleeper but color stays BRASS.

   Store option: Brass (70801) 174. Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Metallic; chemistry: water_based_acrylic.

8. Source DARK BROWN: Dark Brown. Source status: applied. Source finish: unspecified. Pages 2. Section8 steering wheel2, instrument-panel upper housing1, driver seat7 both cushions, passenger seat9 and the inside of the interior tub. WOODGRAIN on the panel face is a separate finish instruction, not a Dark Brown synonym.

   Store option: XF-10 Flat Brown 10 ML (MINI). Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Matte; chemistry: Tamiya X/XF acrylic.

9. Source RED: Red. Source status: applied. Source finish: unspecified. Pages 2. Section9 cab and lower cab sections; section10 exhaust bracket14 and Luberefiner bracket9; section11 hood exterior and fender extensions5; section12 assembled optional sleeper. BODY COLOR alternative in section2 follows the explicit RED exterior. Finish is not named; no automatic Gloss Red normalization.

   Store option: X-7 Red 10 ML (MINI). Previously researched named-color candidate; retained as an unchecked approximation. Original manufacturer code, name, standard and finish are preserved separately. Candidate finish: Gloss; chemistry: Tamiya X/XF acrylic.

10. Source WOODGRAIN: Woodgrain. Source status: applied finish method unspecified. Source finish: unspecified. Pages 2. Section8 explicitly says WOODGRAIN on Instrument Panel Face, Dials BLACK. This is a named decorative finish requirement without a paint code, base color, grain color, coating, ratio or technique. Preserve it as a method/color-choice item; do not invent a separate brown code or imply one solid brown coat is the specified finish.

    Store option: 3G Acrylic Wood Base AK11351. Approximate two-paint hand-grained wood-effect system: dry AK11351 Wood Base, then paint fine AK11106 Mahogany Brown grain strokes. Both components and technique are needed; neither plain brown alone nor a mixed flat color reproduces grain. Exact wood species, hue and sheen are unspecified. No ratio or extra clear coat is prescribed. Lighter base color for the woodgrain effect. Incomplete without darker grain strokes. Candidate finish: not established; chemistry: water_based_acrylic.

    Store option: 3G Acrylic Mahogany Brown AK11106. Approximate two-paint hand-grained wood-effect system: dry AK11351 Wood Base, then paint fine AK11106 Mahogany Brown grain strokes. Both components and technique are needed; neither plain brown alone nor a mixed flat color reproduces grain. Exact wood species, hue and sheen are unspecified. No ratio or extra clear coat is prescribed. Darker grain-stroke color over the dry base. AK’s primary Standard Tools set labels this Dark Wood Grain. Candidate finish: not established; chemistry: water_based_acrylic.

Documented source scheme

name: Documented red Coca-Cola White Western Star with dark-brown interior; first printed wheel and mudflap color choices; family: Not specified; selected indices: WHITE; SILVER; BLACK; FLAT BLACK; TAN/BEIGE; GLOSS BLACK; BRASS; DARK BROWN; RED; supported common assembly indices: WHITE; SILVER; BLACK; FLAT BLACK; TAN/BEIGE; GLOSS BLACK; BRASS; DARK BROWN; RED; unselected finish choice indices: WOODGRAIN; note: Nine named paint colors are required somewhere regardless of the wheel/mudflap branches. First listed wheel-flange choice is SILVER; rear wheel centers use first BODY COLOR choice, i.e. explicit RED exterior, with GLOSS BLACK chassis-color alternative. First mudflap choice is WHITE. Optional sleeper is RED already required for cab/hood. WOODGRAIN remains a visible source requirement requiring the builder to choose a technique; it is not treated as a manufacturer-coded paint or silently omitted. No paint brand/family is printed, so a branded default cannot be claimed as original.

All documented schemes

name: Red cab/hood and optional red sleeper, Coca-Cola edition; source pages: 2; indices: WHITE; SILVER; BLACK; FLAT BLACK; TAN/BEIGE; GLOSS BLACK; BRASS; DARK BROWN; RED; WOODGRAIN; note: Direct assembly paint instructions define the exterior/interior. No dedicated full exterior decal-placement diagram is supplied in the retrieved complete two-page original. Do not use box art to add paints or claim full marking-placement review.

Original code and language conflicts

kind: generic_black_versus_specific_later_finish; source pages: 2; sections: 8; 9; source wording: BLACK (firewall5, section8); FLAT BLACK (Firewall) (assembled interior, section9); handling: Preserve both calls; the later explicit firewall finish is Flat Black. Other unqualified Black assignments remain finish-unspecified. Do not convert all Black to Gloss Black by analogy.; kind: blanket_assembly_color_vs_prior_specific_subassembly_colors; source pages: 1; 2; sections: 2; 6; source wording: SILVER or BODY or CHASSIS COLOR. (wheel flanges, section2); BODY or CHASSIS COLOR. (rear wheels, section2); Paint all parts shown in this section GLOSS BLACK. (section6); handling: The section6 illustration includes already assembled front wheels. Preserve literal broad note but retain the section2 specific wheel options and supplied chrome; do not silently repaint chrome wheels Gloss Black because they are present in a later assembly view.; kind: paint_name_has_no_finish; source pages: 1; 2; names: Black; White; Tan/Beige; Dark Brown; Red; handling: Finish is genuinely unspecified for these names. Source-complete review does not authorize assigning gloss, flat or satin. Later store candidates must disclose any chosen finish.

Other options

type: wheel_flange_color_options; source pages: 1; section: 2; source wording: SILVER or BODY or CHASSIS COLOR.; default: SILVER; alternatives: BODY COLOR (RED specified for cab/hood); CHASSIS COLOR (GLOSS BLACK specified for chassis); scope: Two front outer wheel flanges plus four rear outer and four rear inner wheel flanges; the rear paint caption has leader lines to both rings.; type: rear_wheel_center_color_options; source pages: 1; section: 2; source wording: BODY or CHASSIS COLOR.; default: BODY COLOR (RED); alternatives: CHASSIS COLOR (GLOSS BLACK); scope: Four rear wheel centers; the surrounding rear inner and outer flange rings have their own Silver / Body / Chassis choice.; type: mudflap_color_options; source pages: 2; section: 7; source wording: WHITE or FLAT BLACK; default: WHITE; alternatives: FLAT BLACK; scope: Two rear mudflaps18; both paints are already required elsewhere.; type: optional_sleeper; source pages: 2; sections: 7; 12; source wording: If using sleeper, carriage must be in the rear position, on slide plate. / If sleeper is to be used, install Hose Tenna directly on left frame rail. / Paint assembled Sleeper RED.; default selected: False; additional paint indices: ; description: Optional sleeper adds no new paint. Red is already needed for cab/hood, and Hose Tenna remains Brass. Three sleeper windows are supplied clear.; type: woodgrain_finish; source pages: 2; section: 8; default selected: False; description: Explicit WOODGRAIN instrument-face finish; constituent colors, technique and varnish unspecified. Keep as a builder method choice, not a missing-page assertion.; type: unused_paints; indices: ; description: There is no generic unused paint legend. Every one of the nine paint names and the Woodgrain finish has an explicit use.; type: material_not_paint; source pages: 1; 2; description: Section4 RED and AMBER lens sprues are supplied parts identified as LENSES TO BE USED. Parenthetical (C) is defined as supplied CHROME. Clear backup/headlight/cab/sleeper lenses and windows remain supplied clear. No transparent red/amber, clear varnish, chrome paint or tire paint is named.; type: no_paint_recipe; description: No branded color, FS/RAL code, ratio, primer, clear-coat, weathering, or thinner requirement is supplied. TAN/BEIGE is not a printed mixing formula. No figures or trailer are included in these instructions.

Paint and cement requirements

paint requirement: Manufacturer recommends painting subassemblies before attaching supplied chrome parts, and provides nine applied paint names plus a woodgrain finish. Generic source shades/finishes remain as printed.; plastic cement: status: explicitly required except no-cement joints; source pages: 1; 2; source wording: Use only paint and cement made for styrene. / Cement all parts unless otherwise indicated by the instructions.; note: Scrape paint/chrome from joining areas. Test fit first. Cement is not a paint alternative.; no cement exceptions: source pages: 2; section: 6; description: Axle pins must not be cemented; cement only at marked axle-retainer point; assembled front wheels should rotate.; source pages: 2; section: 11; description: Hood hinges attach to grille only; do not cement at chassis location.; optional supply roles: name: Clear-parts adhesive; status: Optional practical supply, not named by this manual; default selected: False; name: Cyanoacrylate; status: No explicit requirement in this original; do not add as manufacturer-required; default selected: False; name: Additional finishing supplies; status: Compatible brushes, thinner, masking and decal solution may be practical recommendations; exact products are not in the manual; default selected: False

Source review notes

Exact AMT1160 Coca-Cola White Western Star tractor, instruction code A1160-200. Manufacturer-hosted original comprises two complete large sheets with all twelve sections. Current catalog box explicitly confirms 1:25. The instructions themselves do not print scale.; Nine paint colors plus one decorative finish: White, Silver, Black, Flat Black, Tan/Beige, Gloss Black, Brass, Dark Brown, Red; Woodgrain on the instrument face is an additional explicit finish requirement. No lettered palette or paint brand/product codes are printed. Direct paint names, FS absence and finish uncertainty are preserved.; No source-based missing-page hold: a dedicated full exterior decal diagram is absent from this otherwise complete source, but no missing diagram or sheet is referenced. Do not call an unprovided marking chart a missing page or claim an exterior decal-placement audit. No extra paint is inferred from the box artwork.; Keep Black, Flat Black and Gloss Black distinct. Keep Red finish unspecified. Section8 generic BLACK firewall is refined by the explicit section9 FLAT BLACK firewall note; preserve both source statements.; Wheel flanges offer Silver / Body / Chassis color; rear centers Body / Chassis; mudflaps White / Flat Black. No alternative introduces a paint not already used. The optional sleeper is explicitly Red; Hose Tenna relocation does not change Brass.; Parenthetical (C), red/amber lens-sprue labels and clear parts refer to supplied materials, not paint purchases. No transparent amber/red or chrome paint is required merely because these materials are present.; All catalog fields and images retained. Manufacturer PDF link eligibility is supported by this exact Round2 download; this record does not perform link-opening or new-tab UI QA.
