1/32 AH-1G Cobra Early Production 32060
Skip to product information
Build This Aircraft
Complete original paint requirements and documented options reviewed. Source scheme: First manual scheme, variant1 Blue Max; this is guide selection, not a manufacturer designation of default. Original names and codes remain visible. Approximate or cross-family choices start unchecked; dried color, sheen and special effects are not certified equivalents. Tools and thinning purchases are unchecked. Each thinner applies only to its named family. Digital swatches are provisional; out-of-stock cards stay disabled. Source details retain all options, conflicts and original mixtures.
Check the kit guide
View kit instructions (PDF)
ICM paint conversion chart (PDF) ↗
The kit manufacturer’s original instructions open in a new tab. Use the diagrams for color placement and markings.
Original palette, placement, alternatives and source notes
Original paint roles and choices are listed below. Printed alternatives are options for the same role, not additional required purchases or guaranteed color matches. Approximate store options start unchecked.
- Source A: ICM Acrylic 1039 Rubber Black.
All schemes. Source finish: unspecified. Source location: 1; 4; 5; 19; 21; 25; 26; 27; 28. Controls, cockpit floor/instrument panels, rotor blades, anti-glare areas, optional ground-handling wheel tyres
Printed alternatives: Revell 106; Tamiya Acrylic X/XF XF85.
Store option: XF-85 Rubber Black 10 ML (MINI). Instruction-listed Tamiya XF85 is an unchecked cross-family candidate for ICM 1039 Rubber Black. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source B: ICM Acrylic 1023 Aluminium.
All schemes. Source finish: metallic. Source location: 1; 6; 10; 20; 25; 26; 27; 28. Transmission/engine components, nose light housing and rotor drive hardware; optional outboard weapon pod bodies
Printed alternatives: Revell 199; Tamiya Acrylic X/XF XF16.
Store option: XF-16 Flat Aluminum 10 ML (MINI). Instruction-listed Tamiya XF16 is an unchecked cross-family candidate for ICM 1023 Aluminium. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Matte metallic; paint type: Tamiya X/XF acrylic.
- Source C: ICM Acrylic 1027 Gun metal.
All schemes. Source finish: metallic. Source location: 1; 12; 25; 26; 27; 28. Turret guns and optional outboard weapon gun/rocket details
Printed alternatives: Revell 109; Tamiya Acrylic X/XF X10.
Store option: X-10 Gun Metal 10 ML (MINI). Instruction-listed Tamiya X10 is an unchecked cross-family candidate for ICM 1027 Gun metal. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Metallic; paint type: Tamiya X/XF acrylic.
- Source D: ICM Acrylic 1003 Deep Yellow.
All schemes. Source finish: unspecified. Source location: 1; 25; 26; 27; 28. Main rotor blade tips
Printed alternatives: Revell 112; Tamiya Acrylic X/XF XF3.
Store option: XF-3 Flat Yellow 10 ML (MINI). Instruction-listed Tamiya XF3 is an unchecked cross-family candidate for ICM 1003 Deep Yellow. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source E: ICM Acrylic 1006 Deep Orange.
Variant 1 only. Source finish: unspecified. Source location: 1; 25. Horizontal tail surfaces of marking variant 1 only
Printed alternatives: Revell 130; Tamiya Acrylic X/XF X6.
Store option: X-6 Orange 10 ML (MINI) 81506. Instruction-listed Tamiya X6 is an unchecked cross-family candidate for ICM 1006 Deep Orange. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.
- Source F: ICM Acrylic 1072 US Dark Green.
Assembly and exterior of variants 1, 2 and 4. Source finish: unspecified. Source location: 1; 4; 18; 25; 26; 27; 28. Seat cushions, engine-access panel inner surfaces; exterior overall color on variants 1,2,4; optional weapon pod bodies in every scheme
Printed alternatives: Revell 139; Tamiya Acrylic X/XF XF13.
Store option: XF-13 J.A. Green 10 ML (MINI) 81713. Instruction-listed Tamiya XF13 is an unchecked cross-family candidate for ICM 1072 US Dark Green. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source G: ICM Acrylic 1071 Camouflage Green.
Variant 3 only. Source finish: unspecified. Source location: 1; 27. Green exterior camouflage areas of variant 3 only
Printed alternatives: Revell 361; Tamiya Acrylic X/XF XF81.
Store option: XF-81 Dk Green 2 Raf 10 ML (MINI). Instruction-listed Tamiya XF81 is an unchecked cross-family candidate for ICM 1071 Camouflage Green. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source H: ICM Acrylic 1059 Green Ochre.
Variant 3 only. Source finish: unspecified. Source location: 1; 27. Ochre exterior camouflage areas of variant 3 only
Printed alternatives: Revell 188; Tamiya Acrylic X/XF XF59.
Store option: XF-59 Desert Yellow 10 ML (MINI). Instruction-listed Tamiya XF59 is an unchecked cross-family candidate for ICM 1059 Green Ochre. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source J: ICM Acrylic 1033 Sky Grey.
All schemes. Source finish: unspecified. Source location: 1; 4; 5; 19; 25; 26; 27; 28. Seat/armour structures and cockpit side/instrument shrouds; rotor hub/control linkage assembly
Printed alternatives: Revell 371; Tamiya Acrylic X/XF XF19.
Store option: XF-19 Sky Gray 10 ML (MINI). Instruction-listed Tamiya XF19 is an unchecked cross-family candidate for ICM 1033 Sky Grey. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.
- Source K: ICM Acrylic 1014 Clear Green.
All schemes. Source finish: transparent. Source location: 1; 15. Clear navigation light E6
Printed alternatives: Revell 161; Tamiya Acrylic X/XF X25.
Store option: X-25 Clear Green 10 ML (MINI). Instruction-listed Tamiya X25 is an unchecked cross-family candidate for ICM 1014 Clear Green. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: not established; paint type: Tamiya X/XF acrylic.
- Source L: ICM Acrylic 1011 Clear Red.
All schemes. Source finish: transparent. Source location: 1; 10; 15. Clear beacon/navigation lights E2 and E5
Printed alternatives: Revell 731; Tamiya Acrylic X/XF X27.
Store option: X-27 Clear Red 10 ML (MINI). Instruction-listed Tamiya X27 is an unchecked cross-family candidate for ICM 1011 Clear Red. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: not established; paint type: Tamiya X/XF acrylic.
- Source M: ICM Acrylic 1024 Silver.
All schemes. Source finish: metallic. Source location: 1; 10; 12. Nose light reflector B18 and underside light D69
Printed alternatives: Revell 190; Tamiya Acrylic X/XF X11.
Store option: X-11 Chrome Silver 10 ML (MINI) 81511. Instruction-listed Tamiya X11 is an unchecked cross-family candidate for ICM 1024 Silver. Source ICM identity and all other printed alternatives remain visible. No exact physical equivalence is claimed. Candidate finish: Metallic; paint type: Tamiya X/XF acrylic.
Guide scheme
- First printed scheme, variant 1 Blue Max.
All documented schemes
- Scheme 1: 5728 / 47 Blue Max, 2nd Battalion, 20th Artillery Regiment (Aerial Rocket Artillery, ARA) Exterior paint keys: A; D; E; F; J. Outboard weapon paint keys: B; C; F. Instruction page(s): 25.
- Scheme 2: 66-15252 / 15, presumably Cobra NETT Exterior paint keys: A; D; F; J. Outboard weapon paint keys: B; C; F. Instruction page(s): 26.
- Scheme 3: 66-15310, B Battery, 2nd Battalion, 20th Artillery Regiment (Aerial Rocket Artillery, ARA), 1st Cavalry Division (Airmobile), originally assigned Cobra NETT, 1967 Exterior paint keys: A; D; G; H; J. Outboard weapon paint keys: B; C; F. Instruction page(s): 27.
- Scheme 4: 67-15762 / Executioner, 235th AC, Capt Lou Bouault (aircraft commander), Daub Ting, November 1969 Exterior paint keys: A; D; F. Outboard weapon paint keys: B; C; F. Instruction page(s): 28.
Options and supplied materials
- First-scheme paint keys: A; B; C; D; E; F; J; K; L; M.
- Alternate-scheme paint keys: G; H.
Source limitations and material guidance
- This guide follows the first printed Blue Max scheme. The instructions provide four marking options; the manufacturer does not designate a default.
- E is used only by variant 1; G and H are used only by variant 3. Outboard weapon assemblies A–D and five loadout choices on pages 23–24 are optional. Those circled assembly letters are not paint keys.
- The instructions provide no paint mixture or ratio. Brand-column alternatives are choices for the same roles, not additional required paints.
Source references
Paints (12)
0 items selected
Tools and supplies (9)
Select any tools you need to add them with your paint selection.
Checking supply availability…
Paints and supplies sold separately. Prices and availability update from each product.
1/32 AH-1G Cobra Early Production 32060
Regular price
$107.99
