Original paint roles and choices are listed below. Printed alternatives are options for the same role, not additional required purchases or guaranteed color matches. Approximate store options start unchecked.

1. Source H2: GSI Creos Aqueous Hobbycolor H2 BLACK.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 3; 4; 8. Control-stick black areas; main/tail wheel hubs.

   Printed alternatives: GSI Creos Mr. Color C2; Mission Models MMP-047.

   Store option: Gloss Black Mr.Color 10ml C002. Instruction-listed Mr. Color C2 is an unchecked cross-family option for the original Aqueous Hobbycolor H2. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

2. Source H5: GSI Creos Aqueous Hobbycolor H5 BLUE.

   Alternate scheme. Source finish: unspecified. Source location: 2; 13. Scheme C blue rear-fuselage band.

   Printed alternatives: GSI Creos Mr. Color C5; Mission Models MMP-048.

   Store option: Blue Gloss Mr.Color 10ml C005. Instruction-listed Mr. Color C5 is an unchecked cross-family option for the original Aqueous Hobbycolor H5. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

3. Source H11: GSI Creos Aqueous Hobbycolor H11 FLAT WHITE.

   First scheme and common assembly. Source finish: flat. Source location: 2; 11; 12; 13; 14. Spinner spiral/white segment and scheme fuselage bands.

   Printed alternatives: GSI Creos Mr. Color C62; Mission Models MMP-001.

   Store option: Flat White Mr.Color 10ml C062. Instruction-listed Mr. Color C62 is an unchecked cross-family option for the original Aqueous Hobbycolor H11. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

4. Source H12: GSI Creos Aqueous Hobbycolor H12 FLAT BLACK.

   First scheme and common assembly. Source finish: flat. Source location: 2; 3; 4; 9; 11; 12; 13; 14. Cockpit fuel-line connectors, instrument/sight details, optional cockpit lever, spinner black areas.

   Printed alternatives: GSI Creos Mr. Color C33; Mission Models MMP-047.

   Store option: Flat Black Mr.Color 10ml C033. Instruction-listed Mr. Color C33 is an unchecked cross-family option for the original Aqueous Hobbycolor H12. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

5. Source H47: GSI Creos Aqueous Hobbycolor H47 RED BROWN.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 3. Headrest pad on H45.

   Printed alternatives: GSI Creos Mr. Color C41; Mission Models MMP-012.

   Store option: Red Brown Mr.Color 10ml C041. Instruction-listed Mr. Color C41 is an unchecked cross-family option for the original Aqueous Hobbycolor H47. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

6. Source H65: GSI Creos Aqueous Hobbycolor H65 RLM70 BLACK GREEN.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 11; 12; 13; 14. Propeller blades all schemes; overpainted upper-wing crosses in scheme D.

   Printed alternatives: GSI Creos Mr. Color C18; Mission Models MMP-088.

   Store option: Black Green RLM70 Mr.Color 10ml C018. Instruction-listed Mr. Color C18 is an unchecked cross-family option for the original Aqueous Hobbycolor H65. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

7. Source H68: GSI Creos Aqueous Hobbycolor H68 RLM74 DARK GRAY.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 11; 12; 13; 14. Dark gray upper/side camouflage all four schemes.

   Printed alternatives: GSI Creos Mr. Color C36; Mission Models MMP-049.

   Store option: Grey Green RLM74 Mr.Color 10ml C036. Instruction-listed Mr. Color C36 is an unchecked cross-family option for the original Aqueous Hobbycolor H68. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

8. Source H69: GSI Creos Aqueous Hobbycolor H69 RLM75 GRAY.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 11; 12; 13; 14. Gray upper/side camouflage all four schemes.

   Printed alternatives: GSI Creos Mr. Color C37; Mission Models MMP-050.

   Store option: Grey Violet RLM75 Mr.Color 10ml C037. Instruction-listed Mr. Color C37 is an unchecked cross-family option for the original Aqueous Hobbycolor H69. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

9. Source H70: GSI Creos Aqueous Hobbycolor H70 RLM02 GRAY.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 4; 6; 7; 8. Tailwheel leg, gear-bay structures, radiator interior housings/flaps, main legs and inner doors.

   Printed alternatives: GSI Creos Mr. Color C60; Mission Models MMP-056.

   Store option: Gray RLM02 Mr.Color 10ml C060. Instruction-listed Mr. Color C60 is an unchecked cross-family option for the original Aqueous Hobbycolor H70. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

10. Source H77: GSI Creos Aqueous Hobbycolor H77 TIRE BLACK.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 4; 6; 8. Main/tail tyres and circular wheel-bay wall/liner assemblies.

    Printed alternatives: GSI Creos Mr. Color C137; Mission Models MMP-040.

    Store option: Tire Black Mr.Color 10ml C137. Instruction-listed Mr. Color C137 is an unchecked cross-family option for the original Aqueous Hobbycolor H77. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

11. Source H90: GSI Creos Aqueous Hobbycolor H90 CLEAR RED.

    First scheme and common assembly. Source finish: clear. Source location: 2; 7. Port wingtip navigation light.

    Printed alternatives: GSI Creos Mr. Color C47.

    Store option: Gloss Clear Red Mr.Color 10ml C047. Instruction-listed Mr. Color C47 is an unchecked cross-family option for the original Aqueous Hobbycolor H90. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

12. Source H94: GSI Creos Aqueous Hobbycolor H94 CLEAR GREEN.

    First scheme and common assembly. Source finish: clear. Source location: 2; 7. Starboard wingtip navigation light.

    Printed alternatives: GSI Creos Mr. Color C138.

    Store option: Gloss Clear Green Mr.Color 10ml C138. Instruction-listed Mr. Color C138 is an unchecked cross-family option for the original Aqueous Hobbycolor H94. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

13. Source H319: GSI Creos Aqueous Hobbycolor H319 LIGHT GREEN.

    Alternate scheme. Source finish: unspecified. Source location: 2; 12. Scheme B green checkerboard fuselage band; scheme labels this RLM 25.

    Printed alternatives: GSI Creos Mr. Color C319; Mission Models MMP-064.

    Store option: Semi-Gloss Light Green Mr.Color 10ml C319. Instruction-listed Mr. Color C319 is an unchecked cross-family option for the original Aqueous Hobbycolor H319. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

14. Source H324: GSI Creos Aqueous Hobbycolor H324 LIGHT GRAY.

    Alternate scheme. Source finish: unspecified. Source location: 2; 14. Scheme D Italian markings overpaint patches; scheme labels GRIGIO AZURRO CHIARO 1.

    Printed alternatives: GSI Creos Mr. Color C324; Mission Models MMP-116.

    Store option: Flat Light Gray Mr.Color 10ml C324. Instruction-listed Mr. Color C324 is an unchecked cross-family option for the original Aqueous Hobbycolor H324. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

15. Source H413: GSI Creos Aqueous Hobbycolor H413 RLM04 YELLOW.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 3. Yellow cockpit fuel-line U6 areas.

    Printed alternatives: GSI Creos Mr. Color C113; Mission Models MMP-090.

    Store option: Yellow RLM04 Mr.Color 10ml C113. Instruction-listed Mr. Color C113 is an unchecked cross-family option for the original Aqueous Hobbycolor H413. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

16. Source H414: GSI Creos Aqueous Hobbycolor H414 RLM23 RED.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 11; 12; 13; 14. Red trim-tab/control-surface edge details called out on each scheme.

    Printed alternatives: GSI Creos Mr. Color C114; Mission Models MMP-003.

    Store option: Semi-Gloss Red RLM23 Mr.Color 10ml C114. Instruction-listed Mr. Color C114 is an unchecked cross-family option for the original Aqueous Hobbycolor H414. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

17. Source H416: GSI Creos Aqueous Hobbycolor H416 RLM66 BLACK GRAY.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 3; 4; 5; 7; 9. Cockpit tub, seat, sidewalls, controls, panels, rear cover/armour and inner canopy framing.

    Printed alternatives: GSI Creos Mr. Color C116; Mission Models MMP-089.

    Store option: Black Gray RLM66 Mr.Color 10ml C116. Instruction-listed Mr. Color C116 is an unchecked cross-family option for the original Aqueous Hobbycolor H416. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

18. Source H417: GSI Creos Aqueous Hobbycolor H417 RLM76 LIGHT BLUE.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 10; 11; 12; 13; 14. Lower surfaces and side background all schemes; optional centerline tank and carrier.

    Printed alternatives: GSI Creos Mr. Color C117; Mission Models MMP-051.

    Store option: Light Blue RLM76 Mr.Color 10ml C117. Instruction-listed Mr. Color C117 is an unchecked cross-family option for the original Aqueous Hobbycolor H417. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

19. Source MC214: GSI Creos Mr. Metal Color MC214 DARK IRON.

    First scheme and common assembly. Source finish: metallic. Source location: 2; 4; 5. Exhaust stacks I16/I18 and cowling gun muzzles I7.

    Printed alternatives: Mission Models Metallics MMM-001.

    Store option: True Metal Gun Metal AK461. Unchecked polishable dark-metal candidate. AK True Metal Gun Metal AK461 is wax-based and is applied then buffed after drying; it is not Mr. Metal Color MC214 and its dark warm hue can differ. The polishable metallic function is retained, but dried shade and sheen are unverified. Prime first as AK recommends and allow 48 hours to dry. Apply by brush without an assumed thinning ratio. Do not use X20A or Mr. Color thinner with this wax. Candidate finish: Metallic; paint type: wax-based.

20. Source MC218: GSI Creos Mr. Metal Color MC218 ALUMINIUM.

    First scheme and common assembly. Source finish: metallic. Source location: 2; 7. Wing and nose radiator grille/core pieces.

    Printed alternatives: Mission Models Metallics MMM-003.

    Store option: True Metal Dark Aluminium AK456. Unchecked darker aluminium approximation. AK456 is a polishable wax-based metallic and requires different preparation and drying from solvent-based polishable Mr.Metal Color MC218; prime first and allow 48 hours before handling. Its darker tone is a visible limitation, not a certified aluminium hue/shine match. The lighter AK455 candidate is currently out of stock. No X20A or Mr.Color thinner for this wax. Candidate finish: Metallic; paint type: wax-based.

21. Source SM201: GSI Creos Mr. Color Super Metallic SM201 SUPER FINE SILVER.

    First scheme and common assembly. Source finish: metallic. Source location: 2; 4; 8; 13; 14. Tail/main landing-gear polished piston areas; bare-metal underwing panels schemes C/D. Page 8 calls same code SUPER CHROME.

    Printed alternatives: Mission Models Metallics MMC-001.

    Store option: Super Metallic Super Fine Silver Mr.Color 10ml SM201. Exact printed manufacturer paint code and family. Candidate finish: Metallic; paint type: solvent-based acrylic lacquer.

22. Source GX05: GSI Creos Mr. Color GX GX05 SUSIE BLUE.

    Optional paint instead of a decal. Source finish: unspecified. Source location: 2; 4. Paint option for small cockpit instrument/fitting faces H32/H33; decals 33/35 are printed alternatives.

    Store option: Blue Gloss Mr.Color 10ml C005. Unchecked glossy blue Mr.Color lacquer approximation for GX05 Susie Blue. C5 is a different paint from the GX series and can differ in pigment strength, hue and coverage. The source code remains GX05; this optional marking alternative starts unchecked. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

Guide scheme

• WNr. 490617, Uffz. Gerhard Reiher, 8./JG 3, Alperstedt, Germany, November 1944
• Landing gear down. Supplied instrument-face decals are the chosen option; GX05 paint remains optional. The optional tank uses H417, which is already needed for the exterior.

All documented schemes

• Scheme A: WNr. 490617, Uffz. Gerhard Reiher, 8./JG 3, Alperstedt, Germany, November 1944 Color placement: RLM74/75 upper camouflage and mottle over RLM76; white rear band and black/white spinner; RLM70 propeller; red trim details. Blue 2 and unit/insignia markings are decals. Exterior paints: H11; H12; H65; H68; H69; H417; H414. Instruction page(s): 11.
• Scheme B: KG(J) 27, Kaufbeuren, Germany, May 1945 Color placement: RLM74/75/76 camouflage; green/white checkerboard fuselage band uses H319/C319 and H11/C62; red trim and RLM70 propeller. Bottom legend mislabels H69/C37 RLM74, while general legend says RLM75. Exterior paints: H11; H12; H65; H68; H69; H417; H414; H319. Instruction page(s): 12.
• Scheme C: WNr. 150816, JG 300, Bad Langensalza, Germany, April 1945 Color placement: RLM74/75/76 with blue/white/blue fuselage band and silver underwing panels; black/white spinner; red trim and RLM70 propeller. Source prose says unit assignment uncertain. Exterior paints: H11; H12; H65; H68; H69; H417; H414; H5; SM201. Instruction page(s): 13.
• Scheme D: WNr. 491407, Capt. Cesare Marchesi, 3a squadriglia, Io Gruppo Caccia, Aeronautica Nazionale Repubblicana, Lonate Pozzolo, Italy, March 1945 Color placement: RLM74/75/76 with H324/C324 Italian gray markings-overpaint patches and silver underwing panels; RLM70 upper-wing marking overpaint plus propeller; red trim and black/white spinner. Exterior paints: H11; H12; H65; H68; H69; H417; H414; H324; SM201. Instruction page(s): 14.

Options and supplied materials

• Alternative drop tanks and centerline rack. Paints: H417. Not selected for the guide’s initial scheme or configuration. Instruction page(s): 6; 10; 15.
• Instrument face decals versus GX05 paint. Paints: GX05. Not selected for the guide’s initial scheme or configuration. Instruction page(s): 4.
• Open/closed canopy and antenna choices. Paints: H416. No extra paint colors; aerial wire un-coded. Instruction page(s): 7; 9.
• Advertised aftermarket resin, PE and masks. Not selected for the guide’s initial scheme or configuration. Advertisement only; no extra requirements imported. Instruction page(s): 16.

Source limitations and material guidance

• SM201 is labeled SUPER CHROME on page 8, FINE SILVER on page 4 and SUPER FINE SILVER in the main legend. These labels refer to the same printed code.
• H319/C319 is LIGHT GREEN in the main legend and RLM25 in scheme B. H324/C324 is LIGHT GRAY in the main legend and GRIGIO AZURRO CHIARO 1 in scheme D. Scheme B labels H69/C37 RLM74 although the main legend calls it RLM75. The printed codes are retained.
• Black H2/C2 and Flat Black H12/C33 are separate source rows even though both list Mission Models MMP-047. That shared cross-reference does not establish the same finish for both roles. GX05 has no printed Mission Models alternative.
• No paint mixtures are specified. Uncoded wire, clear glazing and supplied decal colors do not add paint requirements. Accessory advertisements are optional purchases, outside the included kit palette.

Source references

• www.eduard.com — original instruction file
