Original paint roles and choices are listed below. Printed alternatives are options for the same role, not additional required purchases or guaranteed color matches. Approximate store options start unchecked.

1. Source H1: GSI Creos Aqueous Hobbycolor H1 WHITE.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 7. Tail/rudder rear light/detail on B22, as arrowed.

   Printed alternatives: GSI Creos Mr. Color C1.

   Store option: Gloss White Mr.Color 10ml C001. Instruction-listed Mr. Color C1 is an unchecked cross-family option for the original Aqueous Hobbycolor H1. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

2. Source H2: GSI Creos Aqueous Hobbycolor H2 BLACK.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 3; 4; 8; 9. Control-stick grip/boot; sight N6; engine front A16; wheel hubs; cooling fan A30.

   Printed alternatives: GSI Creos Mr. Color C2.

   Store option: Gloss Black Mr.Color 10ml C002. Instruction-listed Mr. Color C2 is an unchecked cross-family option for the original Aqueous Hobbycolor H2. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

3. Source H11: GSI Creos Aqueous Hobbycolor H11 FLAT WHITE.

   First scheme and common assembly. Source finish: flat. Source location: 2; 8; 12; 14; 17. Access step C35; scheme A white rudder, C spinner white area, F white identification bands.

   Printed alternatives: GSI Creos Mr. Color C62.

   Store option: Flat White Mr.Color 10ml C062. Instruction-listed Mr. Color C62 is an unchecked cross-family option for the original Aqueous Hobbycolor H11. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

4. Source H12: GSI Creos Aqueous Hobbycolor H12 FLAT BLACK.

   First scheme and common assembly. Source finish: flat. Source location: 2; 8; 12; 13; 14; 15; 16; 17. Main leg flexible/boot areas; exterior anti-glare/exhaust panels and black spinner regions.

   Printed alternatives: GSI Creos Mr. Color C33.

   Store option: Flat Black Mr.Color 10ml C033. Instruction-listed Mr. Color C33 is an unchecked cross-family option for the original Aqueous Hobbycolor H12. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

5. Source H33: GSI Creos Aqueous Hobbycolor H33 RUSSET.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 4; 5. Exhaust pieces C83/C84 and lower exhaust piece C87.

   Printed alternatives: GSI Creos Mr. Color C81.

   Store option: Gloss Russet Mr.Color 10ml C081. Instruction-listed Mr. Color C81 is an unchecked cross-family option for the original Aqueous Hobbycolor H33. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

6. Source H47: GSI Creos Aqueous Hobbycolor H47 RED BROWN.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 3; 7; 9. Optional seat cushion A14, coaming pad A24 and headrest C74.

   Printed alternatives: GSI Creos Mr. Color C41.

   Store option: Red Brown Mr.Color 10ml C041. Instruction-listed Mr. Color C41 is an unchecked cross-family option for the original Aqueous Hobbycolor H47. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

7. Source H64: GSI Creos Aqueous Hobbycolor H64 RLM71 DARK GREEN.

   Alternate scheme C only. Source finish: unspecified. Source location: 2; 14. Scheme C upper camouflage only.

   Printed alternatives: GSI Creos Mr. Color C17.

   Store option: Dark Green RLM71 Mr.Color 10ml C017. Instruction-listed Mr. Color C17 is an unchecked cross-family option for the original Aqueous Hobbycolor H64. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

8. Source H65: GSI Creos Aqueous Hobbycolor H65 RLM70 BLACK GREEN.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 9; 14. Propeller blades; scheme C dark upper camouflage.

   Printed alternatives: GSI Creos Mr. Color C18.

   Store option: Black Green RLM70 Mr.Color 10ml C018. Instruction-listed Mr. Color C18 is an unchecked cross-family option for the original Aqueous Hobbycolor H65. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

9. Source H68: GSI Creos Aqueous Hobbycolor H68 RLM74 DARK GRAY.

   First scheme and common assembly. Source finish: unspecified. Source location: 2; 12; 13; 15; 16; 17. Upper/side camouflage A/B/D/E/F; original camouflage under RLM76 overpaint on B.

   Printed alternatives: GSI Creos Mr. Color C36.

   Store option: Grey Green RLM74 Mr.Color 10ml C036. Instruction-listed Mr. Color C36 is an unchecked cross-family option for the original Aqueous Hobbycolor H68. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

10. Source H69: GSI Creos Aqueous Hobbycolor H69 RLM75 GRAY.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 12; 13; 15; 16; 17. Upper/side camouflage A/B/D/E/F; original camouflage under RLM76 overpaint on B.

    Printed alternatives: GSI Creos Mr. Color C37.

    Store option: Grey Violet RLM75 Mr.Color 10ml C037. Instruction-listed Mr. Color C37 is an unchecked cross-family option for the original Aqueous Hobbycolor H69. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

11. Source H70: GSI Creos Aqueous Hobbycolor H70 RLM02 GRAY.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 5; 6; 7; 8. Wing wheel-well/spar interiors, gun breech portions, cowling rings, legs/doors/linkages and tailwheel metalwork.

    Printed alternatives: GSI Creos Mr. Color C60.

    Store option: Gray RLM02 Mr.Color 10ml C060. Instruction-listed Mr. Color C60 is an unchecked cross-family option for the original Aqueous Hobbycolor H70. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

12. Source H77: GSI Creos Aqueous Hobbycolor H77 TIRE BLACK.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 8. Main and tail wheel tyres, both main-wheel alternatives.

    Printed alternatives: GSI Creos Mr. Color C137.

    Store option: Tire Black Mr.Color 10ml C137. Instruction-listed Mr. Color C137 is an unchecked cross-family option for the original Aqueous Hobbycolor H77. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Matte; paint type: solvent-based acrylic lacquer.

13. Source H90: GSI Creos Aqueous Hobbycolor H90 CLEAR RED.

    First scheme and common assembly. Source finish: clear. Source location: 2; 7. Port wingtip navigation light.

    Printed alternatives: GSI Creos Mr. Color C47.

    Store option: Gloss Clear Red Mr.Color 10ml C047. Instruction-listed Mr. Color C47 is an unchecked cross-family option for the original Aqueous Hobbycolor H90. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

14. Source H94: GSI Creos Aqueous Hobbycolor H94 CLEAR GREEN.

    First scheme and common assembly. Source finish: clear. Source location: 2; 7. Starboard wingtip navigation light.

    Printed alternatives: GSI Creos Mr. Color C138.

    Store option: Gloss Clear Green Mr.Color 10ml C138. Instruction-listed Mr. Color C138 is an unchecked cross-family option for the original Aqueous Hobbycolor H94. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Gloss; paint type: solvent-based acrylic lacquer.

15. Source H413: GSI Creos Aqueous Hobbycolor H413 RLM04 YELLOW.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 12; 13; 14; 15; 16; 17. Yellow lower cowl all schemes; B rear band; C rear band, lower rudder, wing areas/tips.

    Printed alternatives: GSI Creos Mr. Color C113.

    Store option: Yellow RLM04 Mr.Color 10ml C113. Instruction-listed Mr. Color C113 is an unchecked cross-family option for the original Aqueous Hobbycolor H413. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

16. Source H414: GSI Creos Aqueous Hobbycolor H414 RLM23 RED.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 4; 8; 12; 13; 14; 15; 16; 17. Cockpit PE16 handle/control; access step C35 red area; red trim tabs all schemes and red rear band A.

    Printed alternatives: GSI Creos Mr. Color C114.

    Store option: Semi-Gloss Red RLM23 Mr.Color 10ml C114. Instruction-listed Mr. Color C114 is an unchecked cross-family option for the original Aqueous Hobbycolor H414. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

17. Source H416: GSI Creos Aqueous Hobbycolor H416 RLM66 BLACK GRAY.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 3; 4; 7; 9; 10. Cockpit tub, sidewalls, instruments, seat, pedals, coaming structure, canopy inner frames and support.

    Printed alternatives: GSI Creos Mr. Color C116.

    Store option: Black Gray RLM66 Mr.Color 10ml C116. Instruction-listed Mr. Color C116 is an unchecked cross-family option for the original Aqueous Hobbycolor H416. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

18. Source H417: GSI Creos Aqueous Hobbycolor H417 RLM76 LIGHT BLUE.

    First scheme and common assembly. Source finish: unspecified. Source location: 2; 11; 12; 13; 14; 15; 16; 17. Lower/fuselage camouflage background all schemes; extensive exterior overpaint on B; optional drop tanks.

    Printed alternatives: GSI Creos Mr. Color C117.

    Store option: Light Blue RLM76 Mr.Color 10ml C117. Instruction-listed Mr. Color C117 is an unchecked cross-family option for the original Aqueous Hobbycolor H417. Printed name or code discrepancies are described below. Physical color and sheen equivalence are unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

19. Source MC213: GSI Creos Mr. Metal Color MC213 STEEL.

    First scheme and common assembly. Source finish: metallic. Source location: 2; 4. Engine cylinder face A26.

    Store option: True Metal Steel AK457. Unchecked polishable steel-colored wax approximation for MC213 STEEL. AK457 retains a buffable metallic function but is not the original solvent-based polishable Mr.Metal Color or an exact chrome-silver/stainless alloy appearance. Brightness and reflective finish may differ. Prime first, apply by brush and polish after drying; allow 48 hours before handling. No X20A or Mr.Color thinner for wax. Candidate finish: Metallic; paint type: wax-based.

20. Source MC214: GSI Creos Mr. Metal Color MC214 DARK IRON.

    First scheme and common assembly. Source finish: metallic. Source location: 2; 6; 7; 8. Wing-root gun barrels C7, cowling guns C6, optional outer wing gun barrels C4 for schemes B-F.

    Store option: True Metal Gun Metal AK461. Unchecked polishable dark-metal candidate. AK True Metal Gun Metal AK461 is wax-based and is applied then buffed after drying; it is not Mr. Metal Color MC214 and its dark warm hue can differ. The polishable metallic function is retained, but dried shade and sheen are unverified. Prime first as AK recommends and allow 48 hours to dry. Apply by brush without an assumed thinning ratio. Do not use X20A or Mr. Color thinner with this wax. Candidate finish: Metallic; paint type: wax-based.

21. Source SM206: GSI Creos Mr. Color Super Metallic SM206 CHROME SILVER.

    First scheme and common assembly. Source finish: metallic. Source location: 2; 9. Propeller hub A19 and blade-root metal areas.

    Store option: Super Chrome AK9198. Unchecked mirror-chrome effect candidate for SM206 Chrome Silver. AK9198 is an alcohol-based chrome ink with resin, not Mr.Color lacquer, and requires a smooth homogeneous surface. Ready for airbrush use; brush application is also maker-supported. Reflectivity and adhesion are not verified on this kit. Do not use the Mr.Color or X20A thinner recommendations for this product. Candidate finish: Metallic; paint type: alcohol-based chrome ink with resin.

Guide scheme

• WNr. 431007, Maj. Heinz Bär, CO of II./JG 1, Störmede, Germany, April 1944
• Landing gear down. Tank optional. H64 is specific to scheme C.

All documented schemes

• Scheme A: WNr. 431007, Maj. Heinz Bär, CO of II./JG 1, Störmede, Germany, April 1944 Color placement: RLM74/75 over RLM76; yellow lower cowl, red rear band and trim, white rudder; black exhaust/anti-glare panels and spinner. Outer wing guns omitted. Exterior paints: H11; H12; H68; H69; H413; H414; H417. Instruction page(s): 12.
• Scheme B: Hptm. Rolf Hermichen, CO of I./JG 11, Rotenburg, Germany, March 1944 Color placement: RLM74/75 original camouflage overpainted at varying intensity in RLM76; yellow lower cowl and rear band; red trim and black panels/spinner. Exterior paints: H12; H68; H69; H413; H414; H417. Instruction page(s): 13.
• Scheme C: Oblt. Otto Kittel, CO of 3./JG 54, Riga-Skulte, Latvia, August 1944 Color placement: RLM70/71 green upper camouflage over RLM76; yellow lower cowl, rear band, lower rudder and wing identification areas; red trim; black/white spinner. Centerline tank not applicable. Exterior paints: H11; H12; H64; H65; H413; H414; H417. Instruction page(s): 14.
• Scheme D: 6./JG 300, Holzkirchen, Germany, July 1944 Color placement: RLM74/75 over RLM76; yellow lower cowl, red trim, black panels/spinner. Yellow 18 and bar are numbered decals, not added yellow paint roles. Exterior paints: H12; H68; H69; H413; H414; H417. Instruction page(s): 15.
• Scheme E: Fw. Klaus Dietrich, Führerjägerstaffel, Rastenburg, Germany, August 1944 Color placement: RLM74/75 over RLM76; yellow lower cowl, red trim, black panels/spinner. Unit marking/kill markings and spinner spiral are decals. Exterior paints: H12; H68; H69; H413; H414; H417. Instruction page(s): 16.
• Scheme F: WNr. 642962, Major Hans-Günther von Kornatzki, CO of Sturmstaffel 1, Dortmund/Salzwedel, Germany, early 1944 Color placement: RLM74/75 over RLM76 with black/white/black rear identification bands; yellow lower cowl and red trim; solid black spinner. Additional canopy/fuselage armour configuration. Exterior paints: H11; H12; H68; H69; H413; H414; H417. Instruction page(s): 17.

Options and supplied materials

• Two alternative drop-tank types. Paints: H417. Schemes: A; B; D; E; F. Not selected for the guide’s initial scheme or configuration. Instruction page(s): 5; 11.
• PE, decals or molded cockpit instrumentation; optional seat cushion. Paints: H416; H2; H47. Prepainted parts/decals do not create additional colors; shared paints still used elsewhere. Instruction page(s): 3; 4.
• Outer wing guns. Paints: MC214. Schemes: B; C; D; E; F. Not selected for the guide’s initial scheme or configuration. Instruction page(s): 5; 8.
• Additional armour and glazing. Paints: H416. Schemes: F. Not selected for the guide’s initial scheme or configuration. Instruction page(s): 9; 10.
• Open/closed canopy and wheel alternatives. Same source paint roles; supplied masks are not additional paint. Instruction page(s): 8; 9; 10.
• Aftermarket resin/PE accessories. Not selected for the guide’s initial scheme or configuration. Advertisement does not expand boxed finishing requirements. Instruction page(s): 20.

Unspecified and ambiguous details

• C41 lever/control drawing has a red area but no separately linked red paint code in that diagram. Do not treat part identifier C41 as a paint callout. Instruction page(s): 3.
• Tank carrier A11/A18/C61/C62 has no independently printed paint callout; tank RLM76 callout does not establish a distinct carrier recipe. Instruction page(s): 11.
• Stencils are decal references, not paint indices; no added paint inferred from colored stencil artwork. Instruction page(s): 18.

Source limitations and material guidance

• The legend lists GSI Creos Aqueous/Mr. Color, Mr. Metal Color and Super Metallic. It has no Mission Models column. White H1 and Flat White H11 remain separate, as do Black H2 and Flat Black H12.
• Scheme C uses H64/C17 RLM71 with RLM70 instead of the RLM74/75 gray pair. Scheme B retains RLM74/75 beneath uneven RLM76 overpaint. No mixing or dilution ratio is specified.
• Red, white and yellow numbers, insignia and spinner spirals supplied as decals add no paint unless a separate paint callout is shown. Mask, glazing, photo-etch and plastic colors alone do not establish a paint requirement.

Source references

• www.eduard.com — original instruction file
