Original choices and default scheme

Version A, C-47A, 94th Squadron, 439th TCG, USAF, June 1944 (source caption); all approximate store candidates remain unchecked.

Version A is captioned C-47A, 94th Squadron, 439th TCG, USAF, June 1944. Version B is captioned C-47A, MK III, 271th Squadron, RAF, Normandy 1944. These are the original printed captions.

Both schemes use Flat Olive Drab US Army upper surfaces and Flat Dark Ghost Gray undersides, with Flat Black / Flat White invasion stripes. The printed stripe widths are 9.5 mm on the wings and 8.5 mm on the fuselage. Use each original view for the different stripe coverage and markings.

Both schemes specify Gloss Yellow propeller tips, Gloss Red port navigation lights and Gloss Green starboard navigation lights. Version B also explicitly marks the engine-front details Flat Black.

Two seated crew figures are supplied: Flat Military Brown clothing and Flat Leather boots. The same leather color is called out for crew seats and passenger benches. No additional flesh-paint requirement is printed.

Step 5 shows alternative cargo-door positions. Part 58C is for Version A only and uses Flat Gun Metal. Flat Dark Gull Gray appears in the color key without an assembly or marking application callout and remains an unchecked listed option.

Keep the printed 1734 Flat Green Zinc Chrom / FS 33481 and 1741 Flat Dark Ghost Gray / FS 35237 identities together as source conflicts. No exact replacement is selected for either. Model Master 1584 Flat Chromate has no printed FS or Italeri Acrylicpaint code; neither 1184 nor 1734 resolves it.

All 15 printed Italeri Acrylicpaint alternatives are retained separately. Model Master 1402 Flat Steel remains a source reference. No mixtures are specified.

Complete original palette and alternatives

16 original source entries are retained, with 12 mapped paint cards and 19 disabled source, alternative or recipe references. Original paint names identify the source; the candidate names identify the store products. Every approximate candidate starts unchecked.

1. Model Master 1749 Flat Black. Instrument panel, controls, tail wheel, main tires, engine front details, propellers and antenna details; both schemes invasion stripes. Printed standard: F.S. 37038. Store optional candidate: XF-1 Flat Black Mini. Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Tamiya XF Acrylic. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4768AP Flat Black.
2. Model Master 1736 Flat Leather. Pilot boots; crew seats and passenger benches in step 1. Printed standard: F.S. 30100. Store optional candidate: Leather Brown (70871) 147. Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Vallejo Model Color. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4674AP Flat Leather.
3. Model Master 1734 Flat Green Zinc Chrom. Bulkheads, fuselage interior and forward compartment inner surfaces in steps 1–2; spelling and FS preserved as printed. Printed standard: F.S. 33481. Printed 1734 Flat Green Zinc Chrom / FS 33481 identity conflict retained. No hue correction or unsupported substitute. Printed alternative: Acrylicpaint 4852AP Flat Green Zinc Chrom.
4. Model Master 1701 Flat Military Brown. Two supplied seated crew figures 4A clothing, step 1. Printed standard: F.S. 30117. Store optional candidate: US Earth Red (71293). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Vallejo Model Air. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. This is an airbrush-formulated candidate; use the maker’s application guidance. Printed alternative: Acrylicpaint 4770AP Flat Military Brown.
5. Model Master 1740 Flat Dark Gull Gray. Listed in paint key but no application callout found on assembly or marking pages. Printed standard: F.S. 36231. Store optional candidate: Dark Gull Gray (71277). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Vallejo Model Air. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. This is an airbrush-formulated candidate; use the maker’s application guidance. Printed alternative: Acrylicpaint 4755AP Flat Dark Gull Gray.
6. Model Master 1402 Flat Steel. Main gear/struts and hubs, engine center detail, antenna mast detail; steps 3–5. Printed standard: F.S. 37178. Original 1402 Flat Steel retained. No supported exact flat-steel finish candidate is selected. Printed alternative: Acrylicpaint 4679AP Flat Steel.
7. Model Master 1514 Gloss Yellow. Propeller tips, step 4 and both marking schemes. Printed standard: F.S. 13538. Store optional candidate: X-8 Lemon Yellow 10 ML (MINI). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Tamiya X Acrylic. Candidate finish/effect: Gloss. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4642AP Gloss Yellow.
8. Model Master 1710 Flat Dark Green. Cockpit/interior floor, seats supports, controls and forward inner fuselage, steps 1–2. Printed standard: F.S. 34079. Store optional candidate: US Dark Green (71289). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Vallejo Model Air. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. This is an airbrush-formulated candidate; use the maker’s application guidance. Printed alternative: Acrylicpaint 4726AP Flat Dark Green.
9. Model Master 1584 Flat Chromate. Wheel-well interiors, nacelle inner surfaces, engine bulkheads and cowling interiors, steps 3–4. No Italeri Acrylicpaint code printed. Original 1584 Flat Chromate has no printed FS or Acrylicpaint code. 1184 and 1734 are different source identities.
10. Model Master 1785 Flat Rust. Exhausts 46B, step 4. Printed standard: F.S. 30109. Store optional candidate: Rust (71080). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Vallejo Model Air. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. This is an airbrush-formulated candidate; use the maker’s application guidance. Printed alternative: Acrylicpaint 4675AP Flat Rust.
11. Model Master 1405 Flat Gun Metal. Engine cylinder detail, step 4; part 58C in step 5 is Version A only. Printed standard: F.S. 37200. Store optional candidate: XF-56 Metallic Gray 10 ML (MINI). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Tamiya XF Acrylic. Candidate finish/effect: Flat metallic. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4681AP Flat Gun Metal.
12. Model Master 1503 Gloss Red. Port navigation light for Versions A and B. Printed standard: F.S. 11302. Store optional candidate: X-7 Red 10 ML (MINI). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Tamiya X Acrylic. Candidate finish/effect: Gloss. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4605AP Gloss Red.
13. Model Master 1524 Gloss Green. Starboard navigation light for Versions A and B. Printed standard: F.S. 14090. Store optional candidate: X-5 Green 10 ML (MINI). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Tamiya X Acrylic. Candidate finish/effect: Gloss. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4669AP Gloss Green.
14. Model Master 1768 Flat White. Invasion stripes on Versions A and B. Printed standard: F.S. 37875. Store optional candidate: XF-2 Flat White 10 ML (MINI). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Tamiya XF Acrylic. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4769AP Flat White.
15. Model Master 1711 Flat Olive Drab US Army. Upper-surface camouflage, Versions A and B. Printed standard: F.S. 34084. Store optional candidate: XF-62 Olive Drab 10 ML (MINI). Optional approximate candidate supported by the current product identity, photograph and indexed hue/finish. This is not a verified physical or factory-color equivalent. Candidate family: Tamiya XF Acrylic. Candidate finish/effect: Matte. The original Model Master code, printed FS and Italeri Acrylicpaint alternative identify the source, not the substitute formulation. Printed alternative: Acrylicpaint 4728AP Flat Olive Drab US Army.
16. Model Master 1741 Flat Dark Ghost Gray. Underside camouflage, Versions A and B; exact name/FS/paint codes preserved. Printed standard: F.S. 35237. Printed 1741 Flat Dark Ghost Gray / FS 35237 identity conflict retained. No hue correction or unsupported substitute. Printed alternative: Acrylicpaint 4761AP Flat Dark Ghost Gray.

Each selected variant is added once even if it serves more than one source role. Optional tools and supplies start unchecked. Use each thinner only with its named paint family. Each optional thinner is labelled for its compatible paint family. Follow that label and do not mix paint families. Sprays need no added thinner. Digital swatches are browsing aids and do not establish dried hue, sheen, metallic effect or a successful mixture. Unavailable products remain disabled.
