All original paint roles are retained below. Printed alternatives are choices for the same role, not extra required purchases or certified exact matches. A blank source cell remains unspecified.

1. A: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H1 White. Tailplane white identification bands, marking scheme 1; no A paint key is applied to scheme 2. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 1; Mr. Color: 1.

   Store option: Gloss White Mr.Color 10ml C001. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Gloss.

2. B: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H12 Flat Black. Propeller blades in both schemes; black wing/fuselage bands in scheme 2. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 12; Mr. Color: 33.

   Store option: Flat Black Mr.Color 10ml C033. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Matte.

3. C: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H8 Silver. Propeller hub in scheme 1; natural-metal exterior and underside in scheme 2. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 8; Mr. Color: 8.

   Store option: Metallic Silver Mr.Color 10ml C008. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Metallic.

4. D: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H304 Olive Drab. Upper camouflage in scheme 1; upper nose/anti-glare and dorsal area in scheme 2. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 304; Mr. Color: 304.

   Store option: Olive Drab FS34087 Mr.Color 10ml C304. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Semi-gloss.

5. E: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H77 Tire Black. Main wheel and tailwheel tyres in both schemes. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 77; Mr. Color: 137.

   Store option: Tire Black Mr.Color 10ml C137. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Matte.

6. F: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H4 Yellow. Propeller blade tips in both schemes. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 4; Mr. Color: 4.

   Store option: Gloss Yellow Mr.Color 10ml C004. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Gloss.

7. G: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H58 Interior Green. Exposed main wheel-well areas shown in underside views of both schemes; the assembly panels do not extend this key to the cockpit. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 58; Mr. Color: 27.

   Store option: Interior Green Mr.Color C027. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Semi-gloss.

8. H: GSI Creos / Mr.Hobby Aqueous Hobby Color (H series) H53 Neutral Gray. Lower camouflage in scheme 1. Source: Original marking panel.

   Printed paint columns: Mr.Hobby H-series: 53; Mr. Color: 13.

   Store option: Neutral Gray Mr.Color 10ml C013. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Semi-gloss.

Marking choices

• First scheme: P-47D-20RE, 361FS, 356FG, 8th Air Force. It uses paint keys A–H in the H-series family. The store cards offer the printed Mr. Color alternatives and start unchecked.
• Second scheme: P-47D flown by William D. Dunham, Southwest Pacific, 1943. It uses B, C, D, E, F and G. Red-and-white rudder stripes are decals; black wing and fuselage bands use B.

Assembly and materials

• The two assembly steps add no paint callouts or paint mixtures. The bracketed A, B and C labels identify tank subassemblies.
• The instrument panel uses decal 21. The canopy is a clear part; neither adds a separate paint requirement.
• The general symbol key includes cyanoacrylate glue and weight, but neither is specifically called out in the two assembly steps. No ballast quantity, primer or clear coat is specified.
• For decals the source specifies warm water at 40°C for 10 seconds, a clean cloth, and a soft cloth for gently pressing out moisture and bubbles.
