All original paint roles are retained below. Printed alternatives are choices for the same role, not extra required purchases or certified exact matches. A blank source cell remains unspecified.

1. A: GSI Creos / Mr.Hobby Acrysion Color (N series) N12 Flat Black. Overall exterior and propeller blades; cockpit instrument/panel details Source: 4, 8, 9, 10.

   Printed paint columns: Mr.Hobby N-series white box: 12; Mr. COLOR dark box: 33; Vallejo: 950; Model Master: 1749; Tamiya: XF1; Humbrol: 33.

   Store option: Flat Black Mr.Color 10ml C033. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Matte.

2. B: GSI Creos / Mr.Hobby Acrysion Color (N series) N3 Red. Small upper-wing details identified by B leaders; large red walkway outlines are decals 13/15 Source: 9, 10.

   Printed paint columns: Mr.Hobby N-series white box: 3; Mr. COLOR dark box: 3; Vallejo: 908; Model Master: 1503; Tamiya: X7; Humbrol: 19.

   Store option: Gloss Red Mr.Color 10ml C003. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Gloss.

3. C: GSI Creos / Mr.Hobby Acrysion Color (N series) N4 Yellow. Propeller tips and marked C propeller details Source: 9, 10.

   Printed paint columns: Mr.Hobby N-series white box: 4; Mr. COLOR dark box: 4; Vallejo: 953; Model Master: 1514; Tamiya: X8; Humbrol: 69.

   Store option: Gloss Yellow Mr.Color 10ml C004. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Gloss.

4. D: GSI Creos / Mr.Hobby Acrysion Color (N series) N90 Clear Red. Port navigation light and indicated upper red light Source: 9, 10.

   Printed paint columns: Mr.Hobby N-series white box: 90; Mr. COLOR dark box: 47; Vallejo: 934; Model Master: --; Tamiya: X27; Humbrol: --.

   Store option: Gloss Clear Red Mr.Color 10ml C047. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Gloss.

5. E: GSI Creos / Mr.Hobby Acrysion Color (N series) N94 Clear Green. Starboard navigation light and indicated upper green light Source: 9, 10.

   Printed paint columns: Mr.Hobby N-series white box: 94; Mr. COLOR dark box: [blank]; Vallejo: --; Model Master: --; Tamiya: --; Humbrol: --.

   Store option: X-25 Clear Green 10 ML (MINI). Unchecked transparent-green approximation for Acrysion N94 Clear Green. The maker identifies X-25 as clear green for aircraft navigation lights, and the Acrysion chart identifies N94 as gloss clear green. Both preserve a transparent tint, but hue and finished sheen are unverified. X-25 uses Tamiya acrylic chemistry and its own compatible thinner; it is not an Acrysion equivalent or a printed kit alternative. Paint type: Tamiya X/XF acrylic. Candidate finish: Not established.

6. F: GSI Creos / Mr.Hobby Acrysion Color (N series) N1 White. Scheme I propeller hub/cowling white details indicated by F leaders Source: 9.

   Printed paint columns: Mr.Hobby N-series white box: 1; Mr. COLOR dark box: 1; Vallejo: 842; Model Master: 1745; Tamiya: X2; Humbrol: 22.

   Store option: Gloss White Mr.Color 10ml C001. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Gloss.

7. Assembly steps 2, 4: GSI Creos / Mr.Hobby Acrysion Color (N series) N58 Interior Green. Cockpit floor and crew compartment; rear station floor/bulkhead and nose-gear well interior Source: 3, 4.

   Printed paint columns: Mr.Hobby N-series white box: 58; Mr. COLOR dark box: 27.

   Store option: Interior Green Mr.Color C027. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Semi-gloss.

8. Assembly step 4: GSI Creos / Mr.Hobby Acrysion Color (N series) N77 Tire Black. Nosewheel tyre Source: 4.

   Printed paint columns: Mr.Hobby N-series white box: 77; Mr. COLOR dark box: 137.

   Store option: Tire Black Mr.Color 10ml C137. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Matte.

9. Assembly step 4: GSI Creos / Mr.Hobby Acrysion Color (N series) N8 Silver. Nosewheel landing-gear strut B2 Source: 4.

   Printed paint columns: Mr.Hobby N-series white box: 8; Mr. COLOR dark box: 8.

   Store option: Metallic Silver Mr.Color 10ml C008. The instructions list this paint as a different-family alternative. It is an unchecked approximation to the source family; dried hue, sheen and appearance are not certified equivalents. Paint type: solvent-based acrylic lacquer. Candidate finish: Metallic.

Marking choices

• First scheme: P-61B-1-NO “Swing Shift Skipper”, 239440 (42-39440), 547st Night Fighter Squadron (as printed). All nine source paint roles apply.
• Second scheme: P-61B-2-NO “Sleepy Time Gal II”, 239414 (42-39414), 6st Night Fighter Squadron (as printed). The white marking role is omitted.

Original paint families

• The original uses N-prefixed Acrysion colors. These N codes remain unchanged; they are not treated as H-series Aqueous paints.
• Printed Mr. Color alternatives use a different paint family and start unchecked. N94 Clear Green has a blank Mr. Color code box and no printed alternative.
• The Tamiya X-25 Clear Green card is an unchecked store approximation for N94. Its maker identifies a clear green tint for aircraft navigation lights. Hue and finished sheen remain unverified.
• No paint mixture or mixing ratio is specified.

Assembly and materials

• Clear glazing and photo-etched parts are included. Use suitable CA adhesive for photo-etched parts; polystyrene cement serves styrene assembly.
• The original requires 20.0 grams of nose ballast as shown in assembly step 12.
• Assembly step 12 shows two launcher assemblies, two tanks and two bombs installed, but assigns no separate store colors. The guide adds none.
• The two separate marking pages repeat the marking pages in the full original manual. No extra palette is added.
• For decals the source specifies warm water at 40°C for 10 seconds, a clean cloth and a soft cloth.
• Optional tools and thinning purchases start unchecked. Mr. Color thinner applies to the C-series lacquer choices; X-20A applies only to the Tamiya acrylic choice.

Source references

• HobbyBoss official kit and marking page
• Original instruction scan at Hobbysta
• Original instruction scan at Hobbysta
• HobbyBoss original source image
• HobbyBoss original source image
