Original paint roles and choices are listed below. Printed alternatives are options for the same role, not additional required purchases or guaranteed color matches. Approximate store options start unchecked.

1. Source 1: Dark blue.

   Suggested finish. Source finish: unspecified. Source location: 1. Blue: longitudinal dark lateral stripe running along body and tail.

   Store option: X-3 Royal Blue 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Dark blue suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.

2. Source 2: Pink.

   Suggested finish. Source finish: unspecified. Source location: 1. Blue: mouth/tongue area; smaller Beta mouth follows same illustrated subject treatment but no separate color arrow.

   Store option: X-17 Pink 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Pink suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.

3. Source 3: Turquoise.

   Suggested finish. Source finish: unspecified. Source location: 1. Beta: lateral body/tail stripe area.

   Store option: Game Color: Turquoise, 17 ml. 72024. Unchecked broad color-family approximation for X-Plus's uncoded Turquoise suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. This bottle is the legacy 17 ml version. The current 18 ml maker chart confirms the color identity but does not establish identical formulation or sheen for this legacy bottle; exact sheen remains unverified. Candidate finish: Unverified for legacy 17 ml formula; paint type: water-based acrylic.

4. Source 4: Medium gray.

   Suggested finish. Source finish: unspecified. Source location: 1. Diorama exposed rock/stone at back-right of main base illustration.

   Store option: XF-20 Medium Gray 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Medium gray suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.

5. Source 5: Green.

   Suggested finish. Source finish: unspecified. Source location: 1. Small vegetation/ground detail at left side of base.

   Store option: X-5 Green 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Green suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.

6. Source 6: Yellow.

   Suggested finish and optional eye technique. Source finish: unspecified. Source location: 1. Jurassic World logo/nameplate field; also yellow iris stage in optional eye tip.

   Store option: X-8 Lemon Yellow 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Yellow suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. The optional eye mixture uses this same Tamiya X/XF family, but X-Plus supplies no ratios and the replacement mixture has not been tested. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.

7. Source 7: Gray brown.

   Suggested finish. Source finish: unspecified. Source location: 1. Fallen tree/log cut-end/bark area in base illustration.

   Store option: 3G Acrylic Grey Brown AK11125. Unchecked broad color-family approximation for X-Plus's uncoded Gray brown suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Matte; paint type: water-based acrylic.

8. Source 8: Gray green.

   Suggested finish. Source finish: unspecified. Source location: 1. Raptor dorsal skin/body area in separate lower paint illustration.

   Store option: Semi-Gloss Gray Green Mr.Color 10ml C128. Unchecked broad color-family approximation for X-Plus's uncoded Gray green suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Semi-gloss; paint type: solvent-based acrylic lacquer.

9. Source 9: Light gray.

   Suggested finish. Source finish: unspecified. Source location: 1. Light border adjacent to lateral stripe in lower raptor paint illustration.

   Store option: XF-66 Light Gray 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Light gray suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.

10. Source 10: Dark gray.

    Suggested finish and optional skin technique. Source finish: unspecified. Source location: 1. Claw/talon area in lower raptor illustration; also thin dark-gray splatter paint for optional skin-shedding effect.

    Store option: XF-24 Dark Gray 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Dark gray suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.

11. Source 11: Sap green.

    Suggested finish. Source finish: unspecified. Source location: 1. Lower raptor leg/foot skin area in lower paint illustration.

    Store option: XF-5 Flat Green 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded Sap green suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.

12. Source 12: matte white.

    Optional snow effect. Source finish: matte. Source location: 1. Optional snow-effect paint blended with baking soda; not eye whites.

    Store option: XF-2 Flat White 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded matte white suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Matte; paint type: Tamiya X/XF acrylic.

13. Source 13: gold.

    Optional eye detail. Source finish: unspecified. Source location: 1. Optional eye iris gradient or unquantified eye-color blend. Color name alone does not establish a metallic finish.

    Store option: X-12 Gold Leaf 10 ML (MINI). Unchecked broad color-family approximation for X-Plus's uncoded gold suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. The optional eye mixture uses this same Tamiya X/XF family, but X-Plus supplies no ratios and the replacement mixture has not been tested. Candidate finish: Metallic; paint type: Tamiya X/XF acrylic.

14. Source 14: orange.

    Optional eye detail. Source finish: unspecified. Source location: 1. Optional eye iris gradient or unquantified eye-color blend.

    Store option: X-6 Orange 10 ML (MINI) 81506. Unchecked broad color-family approximation for X-Plus's uncoded orange suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. The optional eye mixture uses this same Tamiya X/XF family, but X-Plus supplies no ratios and the replacement mixture has not been tested. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.

15. Source 15: black.

    Optional eye detail. Source finish: unspecified. Source location: 1. Optional eye pupil/radiating iris detail or unquantified eye-color blend.

    Store option: X-1 Black 23 ML (LARGE). Unchecked broad color-family approximation for X-Plus's uncoded black suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. The optional eye mixture uses this same Tamiya X/XF family, but X-Plus supplies no ratios and the replacement mixture has not been tested. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.

16. Source 16: ivory.

    Optional skin-shedding effect. Source finish: unspecified. Source location: 1. Optional skin-shedding technique top color used with chipping liquid.

    Store option: Ivory (71075). Unchecked broad color-family approximation for X-Plus's uncoded ivory suggestion. The original gives no retail paint code or paint family; exact hue and unspecified sheen remain unverified. Candidate finish: Matte; paint type: water-based acrylic.

Guide scheme

• Manufacturer suggested finish; painting is optional. All uncoded store suggestions start unchecked.

All documented schemes

• Illustrated Blue/Beta diorama Scope: Named body/detail/base colors with 11 diagram entries. Instruction page(s): 1.
• Optional snow, eye and skin-shedding enhancements Scope: Three Pro Tips; extra named tip colors and unquantified processes remain optional. Instruction page(s): 1.

Original mixtures

• Optional eye color mixture. yellow + gold + orange + black. No proportions are specified. Use: optional alternative eye technique. Original explicitly calls this a mixture, but gives no proportions, brand or family. No mixing ratio is supplied. Instruction page(s): 1.
• Optional snow texture. matte white paint + baking soda. No proportions are specified. Use: optional snow effect. Adequate baking-soda quantity is qualitative, not a numeric recipe. Instruction page(s): 1.

Painting techniques

• Snow texture (optional). Matte white paint plus an adequate amount of baking soda; dab with brush, optionally blend with unspecified ink, layer/paint over. Baking soda not included. No ratio stated. Instruction page(s): 1.
• Raptor eyes, gradient method (optional). Yellow iris blended into gold, orange, then black radiations toward center. No white eye regions; no ratios. Instruction page(s): 1.
• Raptor eyes, alternate blend method (optional). Outline pupil in yellow, blend gently, then use a mixture of yellow/gold/orange/black; no proportions or compatible paint family specified. Instruction page(s): 1.
• Skin shedding (optional). Thin dark-gray paint splattered with toothbrush, then chipping liquid and ivory; peeling yields a varied shedding effect. Source cautions effect varies with environment; no dilution recipe. Instruction page(s): 1.

Unspecified and ambiguous details

• Teeth on Blue/Beta. no tooth-color callout printed. Do not infer an extra mandatory white paint from grayscale teeth artwork.
• Additional light/dark scale tones beyond named arrows. no fixed shade count or formula. The technique is optional and gives no fixed number of paint shades.

Paint and cement

• Painting: Suggested named colors only; paint parts before assembly as directed on page 2.
• Assembly: Test-fit parts before gluing; plastic-cement/paint safety notes; no proprietary cement code required.

Source limitations and material guidance

• Painting is suggested. Eleven diagram colors and five additional tip colors make 16 named roles. Yellow and Dark gray also appear in techniques. The grayscale instructions supply no brand, code, paint family or numeric ratio; store suggestions remain unchecked.
• The eye technique calls for iris and pupil without white eye areas. Gold is a color name here; a metallic finish is not required. The yellow, gold, orange and black blend has no specified proportions.
• Snow texture and skin shedding are optional. Baking soda, chipping liquid and unspecified ink are materials or process aids. No dilution ratio, fixed scale-tone count or extra tooth color is given.

Source references

• xplusmodelkit.com — original instruction file
