Name: 1 9 Norton Manx 500CC 1951 4602
Brand: Italeri
SKU: 4602
Price: 99.99 USD
Availability: InStock

Build This Motorcycle

Complete original paint requirements and documented options reviewed. Source scheme: Printed Norton Manx 500cc race number 10 scheme, with complete assembly and brass/semigloss-black engine mix. Original names and codes remain visible. Approximate or cross-family choices start unchecked; dried color, sheen and special effects are not certified equivalents. The printed 1:1 recipe belongs to Model Master Acryl Brass 4672 and Semi Gloss Black 4700. The ATOM component suggestions are unchecked; no ATOM mixing ratio or finished effect is validated. Tools and thinning purchases are unchecked. Each thinner applies only to its named family. Digital swatches are provisional; out-of-stock cards stay disabled. Source details retain all options, conflicts and original mixtures.

Original palette, placement, alternatives and source notes

Original paint roles and choices are listed below. Printed alternatives are options for the same role, not additional required purchases or guaranteed color matches. Approximate store options start unchecked.

Source A: Model Master Model Master Acryl 4672 Brass.
Listed in the instructions. Source finish: unspecified. Source location: PDF page 3 A-F legend. Valve-train rocker details and 1:1 mix with Semi Gloss Black for engine crankcase and associated housings (steps 2-3).
Printed alternatives: Model Master Model Master 1782 Brass.
Store option: ATOM METALLIC Brass (20173). Unchecked brass-colored metallic water-based ATOM candidate for Model Master Acryl 4672 Brass. Use with the separate ATOM Satin Black candidate only as an unvalidated same-family option; the original 1:1 ratio describes Model Master paints and is not a validated ATOM recipe. Dried mixed hue and sheen require testing. Candidate finish: Metallic; paint type: water-based acrylic.
Source B: Model Master Model Master Acryl 4678 Silver.
Listed in the instructions. Source finish: unspecified. Source location: PDF page 3 A-F legend. Primary drive chain, oil-tank fittings and fuel tank (steps 4-5,11).
Printed alternatives: Model Master Model Master 1546 Silver.
Store option: X-11 Chrome Silver 10 ML (MINI) 81511. Bright metallic silver candidate; specific metallic grain and sheen not physically verified. Candidate finish: Metallic; paint type: Tamiya X/XF acrylic.
Source C: Model Master Model Master Acryl 4677 Aluminium.
Listed in the instructions. Source finish: unspecified. Source location: PDF page 3 A-F legend. Cylinder, carburetor and transmission/brake/suspension detail (steps 2-5,7-8).
Printed alternatives: Model Master Model Master 1781 Aluminium.
Store option: XF-16 Flat Aluminum 10 ML (MINI). Flat aluminum metallic candidate; source sheen unspecified. Candidate finish: Matte metallic; paint type: Tamiya X/XF acrylic.
Source D: Model Master Model Master Acryl 4695 Gloss Black.
Listed in the instructions. Source finish: unspecified. Source location: PDF page 3 A-F legend. Wheel centers, frame, swingarm, mudguards, shock/fork parts and number plates (steps 1,5-6,8-9,12).
Printed alternatives: Model Master Model Master 1747 Gloss Black.
Store option: X-1 Black 23 ML (LARGE). Gloss black named-color candidate. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.
Source E: Model Master Model Master Acryl 4700 Semi Gloss Black.
Listed in the instructions. Source finish: unspecified. Source location: PDF page 3 A-F legend. 1:1 engine-housing mix component; saddle, brake/chain guard and yoke/number-board/stand details (steps 2-3,6-7,10-12).
Printed alternatives: Model Master Model Master 1597 Semi Gloss Black.
Store option: ATOM COLOR Satin Black (20162). Unchecked satin-black water-based ATOM candidate for Model Master Acryl 4700 Semi Gloss Black. Satin and semi-gloss sheen may differ. ATOM Brass is from this same water-based family; no replacement ratio or mixed-effect match is established. Candidate finish: Satin; paint type: water-based acrylic.
Source F: Model Master Model Master Acryl 4630 Red.
Listed in the instructions. Source finish: unspecified. Source location: PDF page 3 A-F legend. Saddle edge/piping detail (step 6).
Printed alternatives: Model Master Model Master 1503 Red.
Store option: X-7 Red 10 ML (MINI). Gloss red candidate; source finish unspecified. Candidate finish: Gloss; paint type: Tamiya X/XF acrylic.

Guide scheme

Printed Norton Manx 500cc race number 10 scheme, with complete assembly and brass/semigloss-black engine mix

Original mixtures

Brass / Semi Gloss Black engine-housing mix. Model Master Model Master Acryl 4672 Brass (1 part) + Model Master Model Master Acryl 4700 Semi Gloss Black (1 part). Original ratio: 1:1. Placement: Main crankcase and upper crankcase cover, associated housing and timing/side cover. Instruction page(s): PDF page 4, assembly step 2; PDF page 5, assembly step 3.

Source limitations and material guidance

This instruction edition lists six Model Master Acryl paints and six Model Master alternatives. The original engine-housing recipe is Model Master Acryl 4672 Brass plus 4700 Semi Gloss Black in a 1:1 ratio. That ratio applies to those original paints.
ATOM Brass and Satin Black are compatible component candidates from the same paint family, but no substitute ratio, dried hue or mixed sheen has been established. Satin and semi-gloss finishes may differ. Test the result before applying it to the model.
The number 1 decal option uses the same paints as number 10. Chrome removal refers to preparing plated glue joints; it does not specify a separate chrome paint. No other mixture or uncoded color is listed.

Source references

Paints (6)

Select [A] 4672 Brass → approx. MiG Ammo ATOM METALLIC Brass (20173) [A] 4672 Brass → approx. MiG Ammo ATOM METALLIC Brass (20173) $6.00

Shop similar

Select [B] 4678 Silver → approx. Tamiya X-11 Chrome Silver 10 ML (MINI) 81511 [B] 4678 Silver → approx. Tamiya X-11 Chrome Silver 10 ML (MINI) 81511 $2.90

Shop similar

Select [C] 4677 Aluminium → approx. Tamiya XF-16 Flat Aluminum 10 ML (MINI) [C] 4677 Aluminium → approx. Tamiya XF-16 Flat Aluminum 10 ML (MINI) $2.90

Shop similar

Select [D] 4695 Gloss Black → approx. Tamiya X-1 Black 23 ML (LARGE) [D] 4695 Gloss Black → approx. Tamiya X-1 Black 23 ML (LARGE) $3.80

Shop similar

Select [E] 4700 Semi Gloss Black → approx. MiG Ammo ATOM COLOR Satin Black (20162) [E] 4700 Semi Gloss Black → approx. MiG Ammo ATOM COLOR Satin Black (20162) $6.00

Shop similar

Select [F] 4630 Red → approx. Tamiya X-7 Red 10 ML (MINI) [F] 4630 Red → approx. Tamiya X-7 Red 10 ML (MINI) $2.90

Shop similar

0 items selected

Tools and supplies (10)

Select any tools you need to add them with your paint selection.

Checking supply availability…

Paints and supplies sold separately. Prices and availability update from each product.

1 9 Norton Manx 500CC 1951 4602

$99.99

Shipping calculated at checkout

<p>Earn%20[points_amount]%20when%20completing%20this%20purchase.</p>

4602

Quantity

Description

Norton Motors Ltd was founded in 1898 by James Lansdowne Norton, but the brand’s true sporting legacy began in 1907, when Rem Fowler claimed victory at the Isle of Man TT. Between 1930 and 1937, Norton dominated Grand Prix racing, winning an impressive 78 of 92 events.

In the years following World War II, Norton introduced the Manx—designed specifically for the legendary Isle of Man TT from which it takes its name. Built for the racetrack, it was the first to feature the innovative double-cradle “Featherbed” frame, a breakthrough that helped secure a remarkable run of victories between 1947 and 1954.

The iconic single-cylinder Manx 500 achieved legendary status under the hands of Geoff Duke, who rode it to victory at the Isle of Man TT and earned World Championship titles in 1950 and 1951.
