Construction and optional painting

MG Barbatos uses PS runners, including silver-plated parts, gold parts and clear pink parts. Trim the marked under gates carefully. The manual warns that rubbing and solvents can remove plating, so take care when painting or panel lining. Two supplied sticker sheets provide the markings.

The kit includes the sword, 300 mm smooth-bore gun, mace, interchangeable hands and Mikazuki Augus figures. Follow the illustrated weapon storage, extension and cockpit-opening steps. The nineteen recipes include ten for Mikazuki; the gold finish requires a Silver undercoat followed by Clear Yellow 70% and Clear Orange 30%.

Bandai recommends water-based paint. The panel-lining tip suggests a separately sold Gundam Marker or similar without a color or product code. In the figure recipes, RLM75 Gray is printed alongside the Japanese name RLM75 Gray Violet; the printed English Field Gray (1) and Field Gray (2) names are retained as separate colors.

Materials in the parts list: PS: all listed runners; Silver-plated PS: D1 runner; Gold PS: D2 runner; Clear pink PS: H runner.

Printed English Bright blue appears with Japanese Indy Blue; Intermediate blue with Medium Blue; Field gray (2) with Olive Drab; Field gray (1) with Dark Gray. Preserve both language labels as needed without inferring paint codes.

The figure light-gray recipe prints English RLM75 gray with Japanese RLM75 Gray Violet.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

19 printed roles use 25 distinct named ingredients. 15 roles contain mixtures; 1 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body white: White 100% + Navy Blue small dose.
2. Body yellow: White 50% + Yellow 30% + Orange Yellow 20%.
3. Body gold: Undercoat Silver 100%; overcoat Clear Yellow 70% + Clear Orange 30%.
4. Body red: Red 100% + Neutral Gray small dose.
5. Body dark blue: Navy Blue 85% + Black 15% + Red small dose.
6. Weapons brown: Mahogany 80% + Neutral Gray 20%.
7. Body blue: Bright Blue 95% + RLM02 Gray 5%. Candidate recipe incomplete: Bright Blue, RLM02 Gray has no chosen store match.
8. Body gray: Mahogany 40% + White 30% + Black 20% + Khaki 10%.
9. Body green: Metallic Green 100%.
10. Mikazuki Augus hair: Black 65% + Midnight Blue 25% + Bright Blue 10%. Candidate recipe incomplete: Bright Blue has no chosen store match.
11. Mikazuki Augus face: White 60% + Pale Brown 30% + Sail Color 10%. Candidate recipe incomplete: Pale Brown, Sail Color has no chosen store match.
12. Mikazuki Augus clothes blue: Intermediate Blue 55% + Bright Blue 45%. Candidate recipe incomplete: Bright Blue has no chosen store match.
13. Mikazuki Augus clothes green: RLM02 Gray 90% + Green 10%. Candidate recipe incomplete: RLM02 Gray has no chosen store match.
14. Mikazuki Augus clothes yellow: Cream Yellow 35% + Middle Stone 35% + RLM02 Gray 30%. Candidate recipe incomplete: RLM02 Gray has no chosen store match.
15. Mikazuki Augus clothes white: White 100%.
16. Mikazuki Augus clothes gray: Field Gray(2) 80% + Neutral Gray 20%. Candidate recipe incomplete: Field Gray(2) has no chosen store match.
17. Mikazuki Augus clothes dark gray: Field Gray(1) 100%. Candidate recipe incomplete: Field Gray(1) has no chosen store match.
18. Mikazuki Augus clothes light gray: RLM75 Gray 50% + White 20% + Sail Color 20% + Pale Brown 10%. Candidate recipe incomplete: Pale Brown, Sail Color has no chosen store match.
19. Mikazuki Augus back gray: Neutral Gray 100%.

Named ingredients and optional store candidates

19 mapped purchase cards and 6 disabled ingredient references cover all 25 named ingredients. Mapped cards represent 19 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
2. Navy Blue. Approximate candidate: 3G Acrylic Dark Blue AK11181. Dark Blue has a dark navy-blue chart sample. It is a hue-family approximation, distinct from the near-black Midnight Blue candidate. Family: AK 3rd Generation. Finish/effect: matte.
3. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. Yellow is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
4. Orange Yellow. Approximate candidate: 3G Acrylic Golden Yellow AK11041. Golden Yellow supplies a warm yellow-orange approximation, distinct from Orange and Yellow. Family: AK 3rd Generation. Finish/effect: matte.
5. Silver. Approximate candidate: 3G Acrylic Silver AK11209. Silver is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
6. Clear Yellow. Approximate candidate: 3G Acrylic Clear Yellow AK11217. Clear Yellow is a named transparent water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: transparent.
7. Clear Orange. Approximate candidate: 3G Acrylic Clear Orange AK11218. Clear Orange is a named transparent water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: transparent.
8. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
9. Neutral Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. The descriptive Neutral Grey candidate supports a neutral-gray approximation. Its bottle may also serve generic Gray while both ingredient names remain separate. Family: AK 3rd Generation. Finish/effect: matte.
10. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
11. Mahogany. Approximate candidate: 3G Acrylic Mahogany Brown AK11106. Mahogany Brown supplies a named reddish wood-brown approximation. Family: AK 3rd Generation. Finish/effect: matte.
12. Bright Blue. No candidate is chosen for the original Bright blue / Indy Blue shade. The available Deep Sky Blue sample is light cyan.
13. RLM02 Gray. No candidate is chosen because the original does not distinguish the available 1938 and 1941 RLM02 variants.
14. Khaki. Approximate candidate: 3G Acrylic British Khaki AK11127. British Khaki supplies a khaki-brown hue approximation. The source does not specify a British uniform standard. Family: AK 3rd Generation. Finish/effect: matte.
15. Metallic Green. Approximate candidate: 3G Acrylic Metallic Green AK11205. Metallic Green is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
16. Midnight Blue. Approximate candidate: 3G Acrylic Strong Dark Blue AK11187. Strong Dark Blue has a very dark, near-black blue chart sample. It is an approximation to the Midnight Blue hue, distinct from Navy Blue; no manufacturer crosswalk is claimed. Family: AK 3rd Generation. Finish/effect: matte.
17. Pale Brown. No candidate is chosen. The available Light Brown sample is saturated orange-ochre, which does not support this Pale Brown shade.
18. Sail Color. No supported Sail Color candidate is chosen; its specific shade remains a reference.
19. Intermediate Blue. Approximate candidate: 3G Acrylic Intermediate Blue AK11163. Manufacturer Intermediate Blue is a muted gray-blue candidate, supported by its English name and actual current catalog sample. The original pairs English Intermediate Blue with Japanese Medium Blue; both labels remain visible. This uncalibrated approximation is separate from the unsupported dark saturated AK11184 Medium Blue product. Family: AK 3rd Generation. Finish/effect: matte.
20. Green. Approximate candidate: 3G Acrylic Deep Green AK11142. Deep Green supplies a generic opaque green approximation, separate from the Dark Green and special named green ingredients. Family: AK 3rd Generation. Finish/effect: matte.
21. Cream Yellow. Approximate candidate: 3G Acrylic Pastel Yellow AK11037. Pastel Yellow provides a pale cream-yellow candidate. Family: AK 3rd Generation. Finish/effect: matte.
22. Middle Stone. Approximate candidate: 3G Acrylic Middle Stone AK11124. Same descriptive Middle Stone name supports an approximate candidate; exact source formulation is unknown. Family: AK 3rd Generation. Finish/effect: matte.
23. Field Gray(2). No supported candidate is chosen for Field Gray(2), which remains separate from Field Gray(1).
24. Field Gray(1). No supported candidate is chosen for this numbered Field Gray(1) shade.
25. RLM75 Gray. Approximate candidate: 3G Acrylic RLM 75 AK11826. Manufacturer identifies AK11826 as RLM 75; source spelling retained and formulation remains approximate. Family: AK 3rd Generation. Finish/effect: matte.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
