Construction and optional painting

Painting is optional. The original recommends water-based paint and warns against painting ABS. The chain and its two connectors are POM; follow their assembly instructions and preserve moving joints.

The kit supplies color stickers and dry-transfer Gundam decals. Cut and rub the dry transfers through their backing with a blunt tool, following the original directions. These use a rub-down process.

Plastic nippers, tweezers and scissors are shown in the original. Optional panel lining is demonstrated with a water-based Gundam Marker without an exact color or code.

All fifteen recipes are retained, including five for Loran Cehack and four for the cow.

Materials in the parts list: PS; ABS; POM chain and connectors.

Rubbing tool for the supplied dry-transfer Gundam decals: Use the original rub-down application method for these decals. A waterslide decal solution is not selected for this supplied dry-transfer sheet. Reference only; no purchase option is selected.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

15 printed roles use 17 distinct named ingredients. 8 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Turn A: arms, legs etc.: White 100% + Navy Blue small amount.
2. Turn A: chest etc.: Blue 30% + Indy Blue 25% + Cobalt Blue 25% + White 20%. Candidate recipe incomplete: Indy Blue, Cobalt Blue has no chosen store match.
3. Turn A: abdomen etc.: Red 70% + Brown 30%.
4. Turn A: neck area etc.: Yellow 65% + White 30% + Orange 5%.
5. Turn A: face mold: Yellow Green 100%.
6. Turn A: shield reverse etc.: Neutral Gray 90% + Black 10%.
7. Loran Cehack: normal suit: White 100%.
8. Loran Cehack: normal suit line (red): Monza Red 100%. Candidate recipe incomplete: Monza Red has no chosen store match.
9. Loran Cehack: normal suit line (dark): Midnight Blue 100%.
10. Loran Cehack: boots: White 95% + Black 5%.
11. Loran Cehack: visor: Sky Blue 100%.
12. Cow: body/legs white areas: White 100%.
13. Cow: body dark areas: Midnight Blue 100%.
14. Cow: udder: Flesh 95% + Red 5%.
15. Cow: horns: Extra Dark Gray 95% + Black 5%. Candidate recipe incomplete: Extra Dark Gray has no chosen store match.

Named ingredients and optional store candidates

13 mapped purchase cards and 4 disabled ingredient references cover all 17 named ingredients. Mapped cards represent 13 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. AK11001 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
2. Navy Blue. Approximate candidate: 3G Acrylic Dark Blue AK11181. Dark Blue has a dark navy-blue chart sample. It is a hue-family approximation, distinct from the near-black Midnight Blue candidate. Family: AK 3rd Generation. Finish/effect: matte.
3. Blue. Approximate candidate: 3G Acrylic Deep Blue AK11182. Deep Blue supplies an opaque blue candidate, with untested depth and pigment strength. Family: AK 3rd Generation. Finish/effect: matte.
4. Indy Blue. No independently supported water-based Indy Blue hue/formulation is established. A similarly named blue or inferred H/C code is not used.
5. Cobalt Blue. AK11201 Cobalt Blue is explicitly in the metallic range. The source ordinary Cobalt Blue does not establish a metallic effect, so that candidate is rejected.
6. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
7. Brown. Approximate candidate: 3G Acrylic Deep Brown AK11102. Deep Brown supplies a generic brown approximation, kept distinct from Pale Brown, Mahogany and Wood Brown. Family: AK 3rd Generation. Finish/effect: matte.
8. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. AK11044 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
9. Orange. Approximate candidate: 3G Acrylic Medium Orange AK11078. AK11078 Medium Orange has an opaque orange manufacturer-chart and catalog sample. This is an approximate orange-hue candidate; source pigment strength and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
10. Yellow Green. Approximate candidate: 3G Acrylic Interior Yellow Green AK11138. Interior Yellow Green supplies a yellow-green hue approximation. No aircraft-interior standard is assigned to the source. Family: AK 3rd Generation. Finish/effect: matte.
11. Neutral Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. The descriptive Neutral Grey candidate supports a neutral-gray approximation. Its bottle may also serve generic Gray while both ingredient names remain separate. Family: AK 3rd Generation. Finish/effect: matte.
12. Black. Approximate candidate: 3G Acrylic Black AK11029. AK11029 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
13. Monza Red. No independently supported water-based Monza Red candidate is established. Preserve the source name and any bilingual Monza Red / Red Madder note without inventing code equivalence.
14. Midnight Blue. Approximate candidate: 3G Acrylic Strong Dark Blue AK11187. Strong Dark Blue has a very dark, near-black blue chart sample. It is an approximation to the Midnight Blue hue, distinct from Navy Blue; no manufacturer crosswalk is claimed. Family: AK 3rd Generation. Finish/effect: matte.
15. Sky Blue. Approximate candidate: 3G Acrylic Sky Blue AK11175. AK11175 Sky Blue has a light cyan-blue manufacturer-chart and current catalog sample. This is an approximate hue candidate with untested source pigment strength and dried appearance. Family: AK 3rd Generation. Finish/effect: matte.
16. Flesh. Approximate candidate: 3G Acrylic Basic Skin Tone AK11052. Basic Skin Tone supplies a generic flesh-color approximation. No measured likeness or skin tone is claimed. Family: AK 3rd Generation. Finish/effect: matte.
17. Extra Dark Gray. No defensible current water-based store candidate is established for this exact original named ingredient; source label remains unresolved.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
