Construction and optional painting

This Wing Gundam Ver.Ka includes a Buster Rifle with energy packs, a shield, a beam saber and standing and seated Heero figures. The wing and leg assemblies support the Bird Mode transformation. PS outer parts, ABS frame parts and PE polycaps are identified in the parts list; take care to keep the moving joints free.

The supplied markings combine color and marking stickers with dry-transfer Gundam Decals. Cut out a dry transfer, position it securely and rub it down with a rounded tip. Fine tweezers and a rounded burnishing tool can help with this optional detailing. Bandai recommends water-based paint; the color chart supplies nine model recipes but no separate Heero figure palette.

Materials in the parts list: PS runners A, B, C1, C2, D, G, H, I, J, K and SB4; ABS runners E and F; PE PC-120 Plus polycaps.

The original recommends water-based paint and prints legacy Gundam Color alternatives for some complete recipes. Preserve those named and numbered alternatives as shown below. The base recipe ingredients have no printed H/C product numbers; no modern paint-code equivalence is assumed.

Complete original painting recipes

9 printed roles use 15 distinct named ingredients. 8 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. White parts: White 100%; OR legacy Gundam Color White 12.
2. Blue parts: Cobalt Blue 75% + White 20% + Fluorescent Pink 5%; OR legacy Gundam Color Blue 34. Candidate recipe incomplete: Cobalt Blue has no chosen store match.
3. Magazines / ammunition cartridges: Neutral Gray 55% + Shine Red 30% + Black 5% + Indy Blue 10%. Candidate recipe incomplete: Shine Red, Indy Blue has no chosen store match.
4. Elbows, knees, and other joint areas: Mahogany 60% + Neutral Gray 35% + IJA Green (1) 5%. Candidate recipe incomplete: IJA Green (1) has no chosen store match.
5. Red parts: Monza Red 45% + Shine Red 45% + Fluorescent Orange 10%; OR legacy Gundam Color Red 7. Candidate recipe incomplete: Shine Red, Monza Red has no chosen store match.
6. Weapon main body: Neutral Gray 50% + White 40% + Shine Red 5% + Indy Blue 5%. Candidate recipe incomplete: Shine Red, Indy Blue has no chosen store match.
7. Eyes: Yellow Green 30% + White 70% + Clear Blue small unquantified dose.
8. Yellow parts: White 50% + Orange Yellow 40% + Fluorescent Orange 10%; OR legacy Gundam Color Yellow 2.
9. Leg internal frame: Mahogany 50% + Neutral Gray 20% + Sandy Yellow 30%.

Named ingredients and optional store candidates

10 mapped purchase cards and 5 disabled ingredient references cover all 15 named ingredients. Mapped cards represent 10 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
2. Cobalt Blue. AK11201 Cobalt Blue is explicitly in the metallic range. The source ordinary Cobalt Blue does not establish a metallic effect, so that candidate is rejected.
3. Fluorescent Pink. Approximate candidate: 3G Acrylic Flourescent Magenta AK11068. Fluorescent Magenta offers a pink-magenta fluorescent approximation. The primary manufacturer identifies its fluorescent semi-transparent resin; its hue and fluorescence strength may differ. Family: AK 3rd Generation. Finish/effect: fluorescent.
4. Neutral Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. The descriptive Neutral Grey candidate supports a neutral-gray approximation. Its bottle may also serve generic Gray while both ingredient names remain separate. Family: AK 3rd Generation. Finish/effect: matte.
5. Shine Red. No sufficiently supported water-based Shine Red hue/finish candidate is established. Generic red does not establish its named hue or shine.
6. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
7. Indy Blue. No independently supported water-based Indy Blue hue/formulation is established. A similarly named blue or inferred H/C code is not used.
8. Mahogany. Approximate candidate: 3G Acrylic Mahogany Brown AK11106. Mahogany Brown supplies a named reddish wood-brown approximation. Family: AK 3rd Generation. Finish/effect: matte.
9. IJA Green (1). The numbered IJA Green (1) source distinction does not establish a modern AK standard or H/C product code. No candidate is chosen.
10. Monza Red. No independently supported water-based Monza Red candidate is established. Preserve the source name and any bilingual Monza Red / Red Madder note without inventing code equivalence.
11. Fluorescent Orange. Approximate candidate: 3G Acrylic Fluorescent Orange AK11081. The candidate retains both orange hue and fluorescent behavior. White substrate is the paint manufacturer’s application recommendation, not an additional source ingredient. Family: AK 3rd Generation. Finish/effect: fluorescent.
12. Yellow Green. Approximate candidate: 3G Acrylic Interior Yellow Green AK11138. Interior Yellow Green supplies a yellow-green hue approximation. No aircraft-interior standard is assigned to the source. Family: AK 3rd Generation. Finish/effect: matte.
13. Clear Blue. Approximate candidate: 3G Acrylic Clear Blue AK11214. Clear Blue is a named transparent water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: transparent.
14. Orange Yellow. Approximate candidate: 3G Acrylic Golden Yellow AK11041. Golden Yellow supplies a warm yellow-orange approximation, distinct from Orange and Yellow. Family: AK 3rd Generation. Finish/effect: matte.
15. Sandy Yellow. Approximate candidate: 3G Acrylic Sand Yellow AK11035. Sand Yellow supplies a sandy yellow approximation; exact source formulation is unknown. Family: AK 3rd Generation. Finish/effect: matte.

Printed legacy alternatives

These 4 references are separate from the ingredient count and are not additional paint requirements.

• Gundam Color White 12. Original printed alternative for White parts. It replaces that complete recipe; it is not an extra mixture ingredient. No current equivalent is established.
• Gundam Color Blue 34. Original printed alternative for Blue parts. It replaces that complete recipe; it is not an extra mixture ingredient. No current equivalent is established.
• Gundam Color Red 7. Original printed alternative for Red parts. It replaces that complete recipe; it is not an extra mixture ingredient. No current equivalent is established.
• Gundam Color Yellow 2. Original printed alternative for Yellow parts. It replaces that complete recipe; it is not an extra mixture ingredient. No current equivalent is established.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
