Construction and optional painting

This Boba Fett has a molded plastic cape, jetpack, blaster rifle, pistol, interchangeable hands and a display base. Fit the helmet and rangefinder carefully, and follow the under-gate trimming marks. The runners are PS with PE polycaps.

Choose the supplied marking stickers or matching water-slide decals. The fourteen recipes cover the helmet, suit, armor, backpack, cape and weapons. The helmet's dark red area uses Cocoa Brown 90% and Russet (Azuki) 10%. Keep the Blue addition in the body suit and the Green addition in the backpack and arm armor very small; neither has a printed percentage. Bandai recommends water-based paint.

Materials in the parts list: PS: A, B, C, D, E, F and SWB3 runners, including the molded cape; PE: PCF-6AC polycaps.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

14 printed roles use 19 distinct named ingredients. 12 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Helmet green: Neutral Gray 85% + Green 15%.
2. Helmet dark red: Cocoa Brown 90% + Russet (Azuki) 10%. Candidate recipe incomplete: Cocoa Brown, Russet (Azuki) has no chosen store match.
3. Rear helmet dark green: Neutral Gray 50% + Green 50%.
4. Helmet side: Gold 80% + Silver 20%.
5. Body suit: Aircraft Gray 85% + Flat Black 15% + Blue very small dose. Candidate recipe incomplete: Aircraft Gray has no chosen store match.
6. Jacket: Flat White 50% + Light Gray(1) 50%. Candidate recipe incomplete: Light Gray(1) has no chosen store match.
7. Chest armor: Neutral Gray 60% + RLM71 Dark Green 35% + Green 5%.
8. Shoulders and knees yellow: Yellow 60% + Cream Yellow 40%.
9. Backpack and arm armor: Light Gray 95% + Blue 5% + Green very small dose. Candidate recipe incomplete: Light Gray has no chosen store match.
10. Belt: Cocoa Brown 60% + Flat Black 40%. Candidate recipe incomplete: Cocoa Brown has no chosen store match.
11. Left shoulder cape: Olive Drab 80% + Brown 20%. Candidate recipe incomplete: Olive Drab has no chosen store match.
12. Cape center and blaster pistol: Brown 100% + Flat Base small dose. Candidate recipe incomplete: Flat Base has no chosen store match.
13. Waist blaster holster: Flat Black 100%.
14. Blaster rifle: Burnt Iron 100%. Candidate recipe incomplete: Burnt Iron has no chosen store match.

Named ingredients and optional store candidates

11 mapped purchase cards and 8 disabled ingredient references cover all 19 named ingredients. Mapped cards represent 11 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. Neutral Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. The descriptive Neutral Grey candidate supports a neutral-gray approximation. Its bottle may also serve generic Gray while both ingredient names remain separate. Family: AK 3rd Generation. Finish/effect: matte.
2. Green. Approximate candidate: 3G Acrylic Deep Green AK11142. Deep Green supplies a generic opaque green approximation, separate from the Dark Green and special named green ingredients. Family: AK 3rd Generation. Finish/effect: matte.
3. Cocoa Brown. No supported Cocoa Brown candidate is chosen; the original brown shade remains a reference.
4. Russet (Azuki). No supported candidate is chosen for the named Russet (Azuki) shade.
5. Gold. Approximate candidate: 3G Acrylic Gold AK11191. Gold is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
6. Silver. Approximate candidate: 3G Acrylic Silver AK11209. Silver is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
7. Aircraft Gray. No candidate is chosen because the original does not identify a specific aircraft-gray shade.
8. Flat Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a matte opaque 3GEN paint and preserves the explicitly flat black effect. Candidate pigment strength remains untested. Family: AK 3rd Generation. Finish/effect: matte.
9. Blue. Approximate candidate: 3G Acrylic Deep Blue AK11182. Deep Blue supplies an opaque blue candidate, with untested depth and pigment strength. Family: AK 3rd Generation. Finish/effect: matte.
10. Flat White. Approximate candidate: 3G Acrylic White AK11001. White is a matte opaque 3GEN paint and preserves the explicitly flat white effect. Family: AK 3rd Generation. Finish/effect: matte.
11. Light Gray(1). No supported candidate is chosen for this numbered Light Gray(1) shade.
12. RLM71 Dark Green. Approximate candidate: 3G Acrylic RLM 71 AK11822. Manufacturer identifies AK11822 as RLM 71. The original RLM71 name is retained without inventing an H/C product number; formulation remains approximate. Family: AK 3rd Generation. Finish/effect: matte.
13. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. Yellow is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
14. Cream Yellow. Approximate candidate: 3G Acrylic Pastel Yellow AK11037. Pastel Yellow provides a pale cream-yellow candidate. Family: AK 3rd Generation. Finish/effect: matte.
15. Light Gray. No supported Light Gray candidate is chosen. This ingredient remains separate from the jacket’s Light Gray(1).
16. Olive Drab. No candidate is chosen because the original does not identify which Olive Drab shade is intended.
17. Brown. Approximate candidate: 3G Acrylic Deep Brown AK11102. Deep Brown supplies a generic brown approximation, kept distinct from Pale Brown, Mahogany and Wood Brown. Family: AK 3rd Generation. Finish/effect: matte.
18. Flat Base. Flat Base is a flattening additive mixed into paint. No supported equivalent is chosen; matte paint and varnish serve different purposes.
19. Burnt Iron. No supported burnt-iron candidate is chosen. Burnt Tin has a different metal color.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
