Construction and optional painting

Apply the head and shield stickers before closing the parts. The PS kit includes the rifle, beam saber, opening Non-Kinetic Shield and a small CE-1 weapon stand. A PVC wire connects the deployed shield; cut it to the length you want for the pose. One SB-13 blade is listed as a spare.

Choose the optional backpack sticker and the alternative shield stickers shown in the assembly steps. The shield stores the saber grip, and the rifle and saber can be held in either hand. Bandai recommends water-based paint. The Action Base 5 shown supporting the mobile suit is sold separately.

Materials in the parts list: A: PS; B: PS; D: PS; E: PS; G: PS; H: PS; CE-1: PS; SB-13: PS; wire: PVC (1).

RLM75 gray is printed with Japanese RLM75 Gray Violet. Metallic blue green is the English label for Japanese aotake-iro.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

7 printed roles use 14 distinct named ingredients. 7 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body (Purple part): Gray 40% + Purple 30% + White 20% + Cobalt blue 10% + Brown small dose. Candidate recipe incomplete: Cobalt blue has no chosen store match.
2. Body (Red part): Brown 40% + Russet 40% + White 10% + Gray 10% + Red small dose. Candidate recipe incomplete: Russet has no chosen store match.
3. Body (Gray part): RLM75 gray 70% + White 15% + Purple 10% + Red 5%.
4. Beam Rifle (Gray part): Gray 85% + RLM75 gray 10% + White 5%.
5. Sensor (Metallic purple part): Silver 65% + Metallic red 30% + Metallic blue 5%.
6. Sensor (Metallic pink part): Copper 65% + Silver 30% + Metallic red 5%.
7. Beam Rifle Sensor (Metallic green part): Metallic Blue green 65% + Metallic green 35%.

Named ingredients and optional store candidates

12 mapped purchase cards and 2 disabled ingredient references cover all 14 named ingredients. Mapped cards represent 12 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. Neutral Grey is a generic gray approximation; it does not define the distinct named Neutral Gray source as an identical formulation. Family: AK 3rd Generation. Finish/effect: matte.
2. Purple. Approximate candidate: 3G Acrylic Purple AK11073. Purple is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
3. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
4. Cobalt blue. No candidate is chosen. The available AK Cobalt Blue is metallic, while this ingredient calls for an ordinary blue.
5. Brown. Approximate candidate: 3G Acrylic Deep Brown AK11102. Deep Brown supplies a generic brown approximation, kept distinct from Pale Brown, Mahogany and Wood Brown. Family: AK 3rd Generation. Finish/effect: matte.
6. Russet. No supported Russet candidate is chosen. It remains separate from the Red brown ingredient.
7. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
8. RLM75 gray. Approximate candidate: 3G Acrylic RLM 75 AK11826. Manufacturer identifies AK11826 as RLM 75; source spelling retained and formulation remains approximate. Family: AK 3rd Generation. Finish/effect: matte.
9. Silver. Approximate candidate: 3G Acrylic Silver AK11209. Silver is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
10. Metallic red. Approximate candidate: 3G Acrylic Foundry Red AK11203. Manufacturer Foundry Red is explicitly in the metallic range and has a red chart sample. Approximate metallic-red hue/effect candidate; particle size and dried reflectance untested. Family: AK 3rd Generation. Finish/effect: metallic.
11. Metallic blue. Approximate candidate: 3G Acrylic Metallic Blue AK11199. Manufacturer Metallic Blue preserves the named blue metallic effect; exact hue and metal particle behavior untested. Family: AK 3rd Generation. Finish/effect: metallic.
12. Copper. Approximate candidate: 3G Acrylic Copper AK11197. Manufacturer Copper is explicitly metallic and supplies a copper-colored approximation. Family: AK 3rd Generation. Finish/effect: metallic.
13. Metallic Blue green. Approximate candidate: 3G Acrylic Astral Beryllium AK11200. Manufacturer Astral Beryllium is in the metallic range with a blue-green/teal chart sample. This is an approximate hue/effect candidate, never an exact named formula conversion. Family: AK 3rd Generation. Finish/effect: metallic.
14. Metallic green. Approximate candidate: 3G Acrylic Metallic Green AK11205. Metallic Green is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
