Construction and optional painting

Build the head, body, limbs and backpack before adding the Receiver Gun, beam blades, beam sabers and Compo GUND-BIT Shield. The shield separates into Bit Staves for the Bit on Form arrangement. Choose the shown chest insert and sticker options during assembly; Action Base 5 is sold separately.

The five optional color recipes include the metallic-green sensors. Bandai recommends water-based paint and advises against painting the ABS parts. RLM75 Gray is printed with the Japanese name RLM75 Gray-Violet; the small additions remain unmeasured.

Materials in the parts list: PS parts and beam sabers; ABS E parts.

RLM75 Gray (English) is paired with RLM75 Gray-Violet (Japanese); preserve both without assigning an H/C product number.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

5 printed roles use 8 distinct named ingredients. 5 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body white: White 100% + RLM75 Gray small dose.
2. Body pink: White 50% + Wine Red 50%.
3. Backpack gray purple: Gray 50% + White 30% + Purple 20%.
4. Frame gray: RLM75 Gray 95% + Black 5%.
5. Sensor green: Metallic Green 70% + Gold 30%.

Named ingredients and optional store candidates

8 mapped purchase cards and 0 disabled ingredient references cover all 8 named ingredients. Mapped cards represent 8 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
2. RLM75 Gray. Approximate candidate: 3G Acrylic RLM 75 AK11826. Manufacturer identifies AK11826 as RLM 75; source spelling retained and formulation remains approximate. Family: AK 3rd Generation. Finish/effect: matte.
3. Wine Red. Approximate candidate: 3G Acrylic Wine Red AK11096. Wine Red is a dark wine-red opaque candidate supported by the manufacturer name and red-brown chart sample; the dried hue and mixtures remain untested. Family: AK 3rd Generation. Finish/effect: matte.
4. Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. Neutral Grey is a generic gray approximation; it does not define the distinct named Neutral Gray source as an identical formulation. Family: AK 3rd Generation. Finish/effect: matte.
5. Purple. Approximate candidate: 3G Acrylic Purple AK11073. Purple is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
6. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
7. Metallic Green. Approximate candidate: 3G Acrylic Metallic Green AK11205. Metallic Green is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
8. Gold. Approximate candidate: 3G Acrylic Gold AK11191. Gold is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
