Construction and optional painting

Painting is optional. Plastic nippers and tweezers are illustrated as separately sold tools. Use the supplied marking stickers as shown.

The seventeen original roles retain the distinct Steel, RLM75 Gray Violet and Metallic Blue ingredients.

Materials in the parts list: PS.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

17 printed roles use 20 distinct named ingredients. 15 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body (Pink part): White 55% + Salmon Pink 45%. Candidate recipe incomplete: Salmon Pink has no chosen store match.
2. Body (Red part): Red 60% + Salmon Pink 20% + Shine Red 10% + Wine Red 10%. Candidate recipe incomplete: Salmon Pink, Shine Red has no chosen store match.
3. Body (Wine red part): Wine Red 95% + White 5%.
4. Body (Dark wine red part): Wine Red 100% + Black small dose.
5. Body (Dark gray part): Midnight Blue 50% + Mahogany 35% + White 10% + Cocoa Brown 5%. Candidate recipe incomplete: Cocoa Brown has no chosen store match.
6. Body (Dark pink part): Russet 85% + White 15%. Candidate recipe incomplete: Russet has no chosen store match.
7. Body (White part): White 100% + Light Brown small dose. Candidate recipe incomplete: Light Brown has no chosen store match.
8. Vernier (Dark red part): Russet 80% + Shine Red 20%. Candidate recipe incomplete: Shine Red, Russet has no chosen store match.
9. Weapon (Gray part): Gray 90% + Black 10%.
10. Heat hawk (Silver part): Silver 60% + Steel 40%. Candidate recipe incomplete: Steel has no chosen store match.
11. Machine gun (Light gray part): Gray 90% + White 10%.
12. Machine gun (White part): White 90% + Gray 10%.
13. Bazooka (Gray part): RLM75 Gray Violet 90% + White 10%. Candidate recipe incomplete: RLM75 Gray Violet has no chosen store match.
14. Bazooka (Light gray part): RLM75 Gray Violet 60% + White 40% + Purple small dose. Candidate recipe incomplete: RLM75 Gray Violet has no chosen store match.
15. Bazooka (Brown part): Brown 100%.
16. Bazooka (Metallic blue part): Metallic Blue 100%.
17. Mono-eye (Pink part): Pink 90% + Cream Yellow 10%.

Named ingredients and optional store candidates

13 mapped purchase cards and 7 disabled ingredient references cover all 20 named ingredients. Mapped cards represent 13 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. AK11001 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
2. Salmon Pink. No defensible current water-based store candidate is established for this exact original named ingredient; source label remains unresolved.
3. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
4. Shine Red. No sufficiently supported water-based Shine Red hue/finish candidate is established. Generic red does not establish its named hue or shine.
5. Wine Red. Approximate candidate: 3G Acrylic Wine Red AK11096. Wine Red is a dark wine-red opaque candidate supported by the manufacturer name and red-brown chart sample; the dried hue and mixtures remain untested. Family: AK 3rd Generation. Finish/effect: matte.
6. Black. Approximate candidate: 3G Acrylic Black AK11029. AK11029 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
7. Midnight Blue. Approximate candidate: 3G Acrylic Strong Dark Blue AK11187. Strong Dark Blue has a very dark, near-black blue chart sample. It is an approximation to the Midnight Blue hue, distinct from Navy Blue; no manufacturer crosswalk is claimed. Family: AK 3rd Generation. Finish/effect: matte.
8. Mahogany. Approximate candidate: 3G Acrylic Mahogany Brown AK11106. Mahogany Brown supplies a named reddish wood-brown approximation. Family: AK 3rd Generation. Finish/effect: matte.
9. Cocoa Brown. No independently supported Cocoa brown shade is established. Generic Deep Brown or an invented H/C code is not silently substituted.
10. Russet. The printed Russet ingredient remains distinct from Red brown and Cocoa brown. A matching shade is not established.
11. Light Brown. The original Light Brown is Japanese 薄茶色, also paired with Pale Brown on another original. The reviewed orange-ochre sample does not establish that pale-brown ingredient hue; no store candidate is chosen.
12. Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. Neutral Grey is a generic gray approximation; it does not define the distinct named Neutral Gray source as an identical formulation. Family: AK 3rd Generation. Finish/effect: matte.
13. Silver. Approximate candidate: 3G Acrylic Silver AK11209. AK11209 has a matching metallic color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: metallic.
14. Steel. Steel is paired with Japanese black iron color; a matching dark metallic product is not established.
15. RLM75 Gray Violet. No defensible current water-based store candidate is established for this exact original named ingredient; source label remains unresolved.
16. Purple. Approximate candidate: 3G Acrylic Purple AK11073. AK11073 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
17. Brown. Approximate candidate: 3G Acrylic Deep Brown AK11102. Deep Brown supplies a generic brown approximation, kept distinct from Pale Brown, Mahogany and Wood Brown. Family: AK 3rd Generation. Finish/effect: matte.
18. Metallic Blue. Approximate candidate: 3G Acrylic Metallic Blue AK11199. Manufacturer Metallic Blue preserves the named blue metallic effect; exact hue and metal particle behavior untested. Family: AK 3rd Generation. Finish/effect: metallic.
19. Pink. Approximate candidate: 3G Acrylic Pastel Pink AK11059. Pastel Pink supplies a pale pink approximation; source pigment strength is unknown. Family: AK 3rd Generation. Finish/effect: matte.
20. Cream Yellow. Approximate candidate: 3G Acrylic Pastel Yellow AK11037. Pastel Yellow provides a pale cream-yellow candidate. Family: AK 3rd Generation. Finish/effect: matte.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
