Construction and optional painting

Painting is optional. The right shoulder has a metallic-green finish choice, and the left shoulder a metallic-red finish choice; retain their separate sticker/color choices. Two beam sabers, a left-hand choice and optional spare-part uses are shown.

Action Base 7 is sold separately. The instructions also show separately sold nippers and tweezers. The recommended tools below are optional purchases. No separate pilot figure is listed; the cover character artwork is not an additional figure-painting requirement.

Materials in the parts list: PS runners; PE parts.

The source pairs English Russet with Japanese あずき色 (azuki-iro); this is a separate named ingredient, not Orange. RLM75 Gray / Japanese RLM75 gray-violet remains distinct from unnumbered Gray. Intermediate Blue is paired with Japanese ミディアムブルー (Medium Blue); that paired label does not identify a current numbered paint. White includes separate small doses of both Gray and Intermediate Blue.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

12 printed roles use 23 distinct named ingredients. 11 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body white: White 100% + Gray small dose + Intermediate Blue small dose.
2. Body red: Red 50% + Shine Red 30% + White 10% + Russet 10%. Candidate recipe incomplete: Shine Red, Russet has no chosen store match.
3. Body blue: Cobalt Blue 65% + White 20% + Blue 15%. Candidate recipe incomplete: Cobalt Blue has no chosen store match.
4. Body and weapons gray: Gray 85% + Black 15%.
5. Body dark gray: RLM75 Gray 50% + Cobalt Blue 30% + Black 15% + Mahogany 5%. Candidate recipe incomplete: Cobalt Blue has no chosen store match.
6. Body yellow: Yellow 50% + White 20% + Orange Yellow 20% + Cream Yellow 10% + Gray small dose.
7. Shield orange yellow: Orange Yellow 60% + Orange 30% + White 10% + Navy Blue small dose.
8. Beam rifle yellow: Yellow 60% + White 40%.
9. Sensor blue: Blue 45% + Clear Blue 45% + Purple 10%.
10. Right shoulder metallic green: Metallic Green 85% + Gold 15%.
11. Left shoulder metallic red: Metallic Red 100%.
12. Sensor metallic purple: Silver 70% + Metallic Red 20% + Metallic Blue 10%.

Named ingredients and optional store candidates

20 mapped purchase cards and 3 disabled ingredient references cover all 23 named ingredients. Mapped cards represent 20 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
2. Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. Neutral Grey is a generic gray approximation; it does not define the distinct named Neutral Gray source as an identical formulation. Family: AK 3rd Generation. Finish/effect: matte.
3. Intermediate Blue. Approximate candidate: 3G Acrylic Intermediate Blue AK11163. AK11163 Intermediate Blue is a muted gray-blue candidate supported by the manufacturer chart and current catalog sample. Source Japanese Medium Blue is retained separately; no matching code or exact formula is inferred. Family: AK 3rd Generation. Finish/effect: matte.
4. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
5. Shine Red. No sufficiently supported water-based Shine Red hue/finish candidate is established. Generic red does not establish its named hue or shine.
6. Russet. The printed Russet ingredient remains distinct from Red brown and Cocoa brown. A matching shade is not established.
7. Cobalt Blue. AK11201 Cobalt Blue is explicitly in the metallic range. The source ordinary Cobalt Blue does not establish a metallic effect, so that candidate is rejected.
8. Blue. Approximate candidate: 3G Acrylic Deep Blue AK11182. Deep Blue supplies an opaque blue candidate, with untested depth and pigment strength. Family: AK 3rd Generation. Finish/effect: matte.
9. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
10. RLM75 Gray. Approximate candidate: 3G Acrylic RLM 75 AK11826. Manufacturer identifies AK11826 as RLM 75; source spelling retained and formulation remains approximate. Family: AK 3rd Generation. Finish/effect: matte.
11. Mahogany. Approximate candidate: 3G Acrylic Mahogany Brown AK11106. Mahogany Brown supplies a named reddish wood-brown approximation. Family: AK 3rd Generation. Finish/effect: matte.
12. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. Yellow is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
13. Orange Yellow. Approximate candidate: 3G Acrylic Golden Yellow AK11041. Golden Yellow supplies a warm yellow-orange approximation, distinct from Orange and Yellow. Family: AK 3rd Generation. Finish/effect: matte.
14. Cream Yellow. Approximate candidate: 3G Acrylic Pastel Yellow AK11037. Pastel Yellow provides a pale cream-yellow candidate. Family: AK 3rd Generation. Finish/effect: matte.
15. Orange. Approximate candidate: 3G Acrylic Medium Orange AK11078. AK11078 Medium Orange has an opaque orange manufacturer-chart and catalog sample. This is an approximate orange-hue candidate; source pigment strength and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
16. Navy Blue. Approximate candidate: 3G Acrylic Dark Blue AK11181. Dark Blue has a dark navy-blue chart sample. It is a hue-family approximation, distinct from the near-black Midnight Blue candidate. Family: AK 3rd Generation. Finish/effect: matte.
17. Clear Blue. Approximate candidate: 3G Acrylic Clear Blue AK11214. Clear Blue is a named transparent water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: transparent.
18. Purple. Approximate candidate: 3G Acrylic Purple AK11073. Purple is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
19. Metallic Green. Approximate candidate: 3G Acrylic Metallic Green AK11205. Metallic Green is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
20. Gold. Approximate candidate: 3G Acrylic Gold AK11191. Gold is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
21. Metallic Red. Approximate candidate: 3G Acrylic Foundry Red AK11203. Manufacturer Foundry Red is explicitly in the metallic range and has a red chart sample. Approximate metallic-red hue/effect candidate; particle size and dried reflectance untested. Family: AK 3rd Generation. Finish/effect: metallic.
22. Silver. Approximate candidate: 3G Acrylic Silver AK11209. Silver is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
23. Metallic Blue. Approximate candidate: 3G Acrylic Metallic Blue AK11199. Manufacturer Metallic Blue preserves the named blue metallic effect; exact hue and metal particle behavior untested. Family: AK 3rd Generation. Finish/effect: metallic.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
