Construction and optional painting

Follow the Advanced MS Joint assembly sequence and trim the marked under gates before fitting the armor. RG Destiny uses PS, ABS and PP parts. Bandai recommends water-based paint and advises against painting the ABS mechanical sections because paint can cause breakage.

The supplied Realistic Decals are adhesive marking stickers. The kit includes the rifle, shields, Arondight sword, beam cannon and beam saber or boomerang options. The illustrated Action Base 2 is sold separately. The seventeen paint recipes include eight for Shinn Asuka; the beam-cannon blend specifically uses Olive Gray 60%.

Materials in the parts list: PS: armor, weapons and clear effect parts; ABS and PP: B Advanced MS Joint runner.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

17 printed roles use 18 distinct named ingredients. 15 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Face white: White 95% + Gray 5% + Blue small dose.
2. Shin light gray: White 90% + Gray 10%.
3. Chest blue: Indy Blue 100% + Red small dose + White small dose. Candidate recipe incomplete: Indy Blue has no chosen store match.
4. Waist and legs red: Monza Red 60% + Shine Red 40%. Candidate recipe incomplete: Monza Red, Shine Red has no chosen store match.
5. Antenna yellow: Yellow 55% + White 30% + Orange Yellow 15%.
6. Sword light violet: Violet 60% + White 40%.
7. Beam cannon green: Olive Gray 60% + Dark Green 30% + Green 10%. Candidate recipe incomplete: Olive Gray has no chosen store match.
8. Wrists dark gray: Black 70% + White 30%.
9. Wings black: Black 100% + White small dose.
10. Shinn Asuka skin: White 50% + Flesh 50%.
11. Shinn Asuka hair black: Blue 80% + Black 15% + Red 5%.
12. Shinn Asuka normal suit white: White 100%.
13. Shinn Asuka normal suit red: Maroon 100% + Blue small dose.
14. Shinn Asuka normal suit dark gray: Black 70% + White 30%.
15. Shinn Asuka normal suit yellow: Yellow 60% + Orange Yellow 40%.
16. Shinn Asuka normal suit gray: Aircraft Gray 95% + Black 5%. Candidate recipe incomplete: Aircraft Gray has no chosen store match.
17. Shinn Asuka helmet visor sky blue: Sky Blue 100%.

Named ingredients and optional store candidates

13 mapped purchase cards and 5 disabled ingredient references cover all 18 named ingredients. Mapped cards represent 13 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
2. Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. Neutral Grey is a generic gray approximation; it does not define the distinct named Neutral Gray source as an identical formulation. Family: AK 3rd Generation. Finish/effect: matte.
3. Blue. Approximate candidate: 3G Acrylic Deep Blue AK11182. Deep Blue supplies an opaque blue candidate, with untested depth and pigment strength. Family: AK 3rd Generation. Finish/effect: matte.
4. Indy Blue. No supported candidate is chosen for the named Indy Blue shade.
5. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
6. Monza Red. No supported candidate is chosen for the named Monza Red shade.
7. Shine Red. No candidate is chosen that supports both the named Shine Red shade and its shine.
8. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. Yellow is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
9. Orange Yellow. Approximate candidate: 3G Acrylic Golden Yellow AK11041. Golden Yellow supplies a warm yellow-orange approximation, distinct from Orange and Yellow. Family: AK 3rd Generation. Finish/effect: matte.
10. Violet. Approximate candidate: 3G Acrylic Deep Violet AK11072. Violet is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
11. Olive Gray. No supported Olive Gray candidate is chosen. Olive Drab is a separate color.
12. Dark Green. Approximate candidate: 3G Acrylic Dark Green AK11146. Same descriptive Dark Green name supports an approximate opaque candidate. Family: AK 3rd Generation. Finish/effect: matte.
13. Green. Approximate candidate: 3G Acrylic Deep Green AK11142. Deep Green supplies a generic opaque green approximation, separate from the Dark Green and special named green ingredients. Family: AK 3rd Generation. Finish/effect: matte.
14. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
15. Flesh. Approximate candidate: 3G Acrylic Basic Skin Tone AK11052. Basic Skin Tone supplies a generic flesh-color approximation. No measured likeness or skin tone is claimed. Family: AK 3rd Generation. Finish/effect: matte.
16. Maroon. Approximate candidate: 3G Acrylic Wine Red AK11096. Manufacturer Wine Red supplies an approximate dark maroon/wine red hue. The source Maroon remains a separate uncoded name. Family: AK 3rd Generation. Finish/effect: matte.
17. Aircraft Gray. No candidate is chosen because the original does not identify a specific aircraft-gray shade.
18. Sky Blue. Approximate candidate: 3G Acrylic Sky Blue AK11175. Same descriptive Sky Blue name supports a pale blue candidate. Separate Light Blue ingredients are retained even when sharing this bottle. Family: AK 3rd Generation. Finish/effect: matte.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
