14 original source colors are preserved below. Store candidates identify the chosen paint family; colors without a suitable product remain as source references.

Version A and Version B painting

• The complete 12-page Revision 1 manual, document 842090762, includes steps 1–16 and both final painting/decal sheets. Version A uses Tamiya TS-20 Metallic Green for the cab/body. Version B uses Tamiya TS-26 Pure White. Choose one body scheme; TS-20 is the default and TS-26 starts unchecked.
• The assembly Gloss White 4696AP, FS17875 is a separate requirement from the Version B TS-26 body color. It paints the marked detail at step 4 and engine fan/accessory areas at step 5. Keep both original references even when building the white version.
• The final Version A and B sheets both add F Gunship Gray 4752AP, FS36118 and Semi-Gloss Insignia Red, FS21136. The red is a Federal Standard color reference for the frame/chassis with no paint brand or commercial product code; step 1 sends the builder to the final color plate. It remains a disabled reference because no defensible exact-finish product is selected.
• Alternative nationality decals and license-plate templates are retained on both final sheets. Use the selected version’s front, side and rear views and the final TIR decal placement. The original does not print a paint mixture or ratio.

Engine, cab and clear-part details

• The full A–J assembly legend covers chassis fittings, engine, wheel groups and cab interior. Flat Rust 4675AP is used on exhaust/manifold pipes; Flat Gun Metal 4681AP is used on the engine body and marked details; Gloss Light Blue 4650AP covers the marked engine bank/cover assemblies.
• Flat Gull Gray 4763AP is explicitly printed with FS36622 in this manual and used on cab interior areas, seats, floor, shelving and upper interior. Preserve that literal pairing; it differs from older Model Master Acryl 4763 associated with FS36440 in other kits.
• Paint the front turn-signal clear parts 186F/189F and rear clear-light part 135F from the inside as instructed. The source calls for Gloss Orange 4682AP and Gloss Red 4605AP; it does not name transparent paints for those roles.
• Keep joints or movable parts unglued where the original indicates. Steps 9–12 cover cab opening, glazing, lights, mirrors and side steps; steps 15–16 complete cargo box, canvas and spare wheel. There are no figures or crew in the parts inventory or assembly.

Paint family, finish and optional supplies

• TS-20 and TS-26 are exact Tamiya TS aerosol references. They are synthetic lacquer sprays; normal aerosol use needs no separate thinner. TS-20 is described here only as metallic because primary regional descriptions disagree on its gloss versus semi-gloss sheen; the kit itself prints Metallic Green without a sheen.
• All Italeri-source store candidates are approximate and start unchecked. Source names/codes and FS references remain distinct from candidate names. For example, the manufacturer’s approximate conversion for Flat Rust 4675AP is Tamiya XF-9 Hull Red; this does not rename the source color.
• Use X-20A for Tamiya X/XF acrylic candidates, Vallejo thinner for Model Air and AK 3GEN thinner for the AK FS36622 candidate. These are different chemistries from the TS body sprays. Allow each layer to cure and test the chosen paint/decal stack.
• Cement, cutters, knife, sanding, detail brushes, masking, clear-parts glue, decal solution and the relevant thinners are optional purchases and start unchecked. No guessed primer, varnish or flattening recipe is added for FS21136.

Complete original color list

1. A — 4696AP Gloss White (FS17875). Assembly details: page 5 step 4 part 64B center; page 6 step 5 marked engine fan/pulley/accessory areas. Separate from Version B body PureWhite TS-26. Candidate: X-2 White 10 ML (MINI). Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: gloss.
2. B — 4605AP Gloss Red (FS11302). Rear clear-light red areas 135F, page 9 step 14; paint from inside. Final versions A/B legends also repeat Gloss Red. Candidate: X-7 Red 10 ML (MINI). Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: gloss.
3. C — 4682AP Gloss Orange (FS12197). Front clear turn-signal parts 186F/189F, page 8 step 11; rear clear-light areas 135F, page 9 step 14. Paint clear parts from inside. Final versions A/B also repeat Gloss Orange. Candidate: X-6 Orange 10 ML (MINI) 81506. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: gloss.
4. D — 4768AP Flat Black (FS37038). page 5 step 4 battery/part 64B border 65B; page 6 step 5 belt/intake details; page 7 step 7 hoses 137C/reservoir 139C/canister 138C/141A and step 8 interior 143A/144A/145E/142C; page 8 step 9 wipers 174C/175C; page 9 step 13 grilles 211C/192A; final versions A/B. Candidate: XF-1 Flat Black Mini. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: flat.
5. E — 4678AP Metal Gloss Silver (FS17178). page 6 step 5 turbo 116A and step 6 wheel-hub groups; page 7 step 7 hub 133B; page 8 step 11 handles 191A/front light housings and step 12 footplates 199C/200C; page 9 step 13 footplate; page 10 step 16 sparewheel; final versions A/B. Candidate: X-11 Chrome Silver 10 ML (MINI) 81511. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: gloss metallic silver.
6. F — 4677AP Metal Flat Aluminium (FS37178). page 5 step 4 steps 74C/76C; page 6 step 5 engine rocker-cover parts 110A/107A. Candidate: XF-16 Flat Aluminum 10 ML (MINI). Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: flat metallic aluminum.
7. G — 4675AP Flat Rust (FS30109). page 6 step 5 exhaust/manifold pipes 113A/114A/115A. Candidate: XF-9 Hull Red 10 ML (MINI). Italeri’s conversion chart suggests XF-9 Hull Red for the original Flat Rust 4675AP. The source and candidate names remain distinct; compare a dried sample. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: flat.
8. H — 4681AP Flat Gun Metal (FS37200). page 6 step 5 engine-body and marked engine detail areas including 97A/98A and main engine. Candidate: XF-56 Metallic Gray 10 ML (MINI). Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: flat metallic gray.
9. I — 4763AP Flat Gull Gray (FS36622). page 7 step 8 marked cab interior: seat cushions/backrests, floor/surrounding interior 145E, shelving 157E and upper interior 156E. Candidate: 3G Acrylic Camouflage Grey FS 36622 AK11890. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: water based acrylic. Finish/effect: matte.
10. J — 4650AP Gloss Light Blue (FS15200). page 6 step 5 engine bank/cover assemblies 91A/92A. Candidate: X-14 Sky Blue 10 ML (MINI). Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya water-soluble acrylic resin; organic solvent/water carrier. Finish/effect: gloss.
11. TS-20 Metallic Green. Version A final front/side/rear painting sheet; green cab/body scheme. Candidate: TS-20 Metallic Green. Exact printed Tamiya TS family and color code. Choose this aerosol only for the matching body version. Paint family: synthetic lacquer aerosol. Finish/effect: metallic; sheen not asserted because official regional page title says gloss but body says semi-gloss.
12. 4752AP F Gunship Gray (FS36118). Both final Version A and Version B painting-sheet legends. Candidate: Medium Gunship Gray (71097). Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: water based acrylic. Finish/effect: matte.
13. Semi-Gloss Insignia Red (FS21136). Both final Version A and Version B painting sheets, frame/chassis red indicated by the final color plates. No brand or product code printed. page 4 step 1 explicitly refers frame painting to final color plate. No suitable semi-gloss FS21136 store paint has been established. A gloss FS11136 product is not the same finish.
14. TS-26 Pure White. Version B final front/side/rear painting sheet, white cab/body scheme with STARTRUCK LTD decals. Separate from assembly Gloss White 4696AP. Candidate: TS-26 Pure White Spray. Exact printed Tamiya TS family and color code. Choose this aerosol only for the matching body version. Paint family: synthetic lacquer aerosol. Finish/effect: gloss.

Full original Italeri 90762 instructions and both painting sheets, linked by official distributor Carson. The complete original includes the final painting instructions.

View this exact kit.
