13 original source colors are preserved below. Store candidates identify the chosen paint family; colors without a suitable product remain as source references.

Exact kit and marking options

• These instructions describe the F-89C, with tip tanks. The two marking options are F-89C 51-5843 of the Montana Air National Guard, 186th Fighter Interceptor Squadron, 120th Fighter Group, Great Falls, May 1958; and F-89C 51-746 of the 84th Fighter-Interceptor Squadron, Hamilton Air Force Base, California, 1952.
• Montana markings use G / 54 Midnight blue gloss on the tip tanks and fin areas; the second option uses I / 08 Black matt there. Yellow stripes and emblems are decals; no yellow paint has been added.
• The original instruction cover says 50th Anniversary while the 05650 box and decal sheet identify the 75th Anniversary release. Instruction document 05650-0379 and decal 05650-0240C bind this package. Some promotional text describes an F-89D; follow the actual F-89C drawings.
• The set supplies four pots: 08, 54, 90 and 91. They are only part of the complete 13-color A–M legend. The 54 pot says Night blue, gloss while the booklet says Midnight blue gloss.

Assembly, optional parts and complete palette

• All 16 numbered instruction pages are included in the original gallery. Assembly runs through steps 1–29 and marking plans through steps 30–33. All 13 legend colors remain listed, including 57 Grey matt and 301 White silk matt whose exact small detail placements are difficult to localize in the gallery.
• Both pilot figures and associated parts are shaded Parts not used in the parts map. The assembly sequence does not install or paint them. No flesh, uniform or flight-suit colors are added from promotional figures.
• Open/closed canopy, undercarriage and detail choices follow the original symbols. Rocket step 20 calls for F / 371 Light grey silk matt and M / 67 Greenish grey matt. These are retained even if the rockets are omitted.
• The original specifies no paint mixture or mixing ratio. Use the complete diagrams for each small paint flag and your chosen marking option.

Store candidates and supplies

• No exact Revell-family paint product is selected. Each mapped card preserves its original Revell code and name before the approximate store candidate. Four silk-matt colors remain as disabled references. All candidate purchases start unchecked.
• The numerical Revell references are not a declaration of paint chemistry. Revell Aqua Color manufacturer swatches help compare the same numeric colors; the substitute families are stated separately. Illustrated swatches are not measured dried-paint standards. Metallic reflection, clear finishes and final sheen require a test piece.
• The Tamiya XF-16 candidate is flat metallic aluminium; use X-20A only for Tamiya X/XF acrylics. Use AK 3GEN thinner only for the AK 3GEN candidates. Pro Acryl Blue Black is a water-based matt acrylic. The darker AK11208 candidate for source 91 is a tentative metallic option and needs particular shade review.
• Tools, extra cement, brushes, masking, clear-parts glue, decal solution and thinner are optional purchases. Check the supplied set contents before buying duplicates. No primer, clear coat or additional pilot color is added as a kit requirement.

Complete original color list

1. A — Revell 99 Aluminium metallic. Required original color legend; see scheme and assembly notes. Candidate: XF-16 Flat Aluminum 10 ML (MINI). Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Tamiya X/XF acrylic (water-soluble acrylic resin with organic solvent/water carrier). Finish/effect: Metallic, flat.
2. B — Revell 330 Fiery red silk matt. Required original color legend; see scheme and assembly notes. A swatch candidate exists, but its native silk-matt/satin finish lacks sufficient primary confirmation. No purchase product is selected.
3. C — Revell 09 Anthracite matt. Required original color legend; see scheme and assembly notes. Candidate: 3G Acrylic Oxford AK11188. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: AK 3rd Generation water-based acrylic. Finish/effect: Matt.
4. D — Revell 57 Grey matt. Required original color legend; see scheme and assembly notes. Candidate: 3G Acrylic RAF Medium Sea Grey BS381C/637 AK11843. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: AK 3rd Generation water-based acrylic. Finish/effect: Matt.
5. E — Revell 301 White silk matt. Required original color legend; see scheme and assembly notes. No sufficiently close, finish-confirmed single-product satin-white candidate is established.
6. F — Revell 371 Light grey silk matt. Required original color legend; see scheme and assembly notes. No sufficiently close, finish-confirmed single-product light-grey satin candidate is established.
7. G — Revell 54 Midnight blue gloss. Required original color legend; see scheme and assembly notes. Candidate: X-3 Royal Blue 10 ML (MINI). Approximate gloss-color candidate with a related hue and the required finish. The candidate shade differs; compare a dried sample before use. Paint family: Tamiya X/XF acrylic (water-soluble acrylic resin with organic solvent/water carrier). Finish/effect: Gloss.
8. H — Revell 90 Silver metallic. Required original color legend; see scheme and assembly notes. Candidate: 3G Acrylic Aluminium AK11207. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: AK 3rd Generation water-based acrylic. Finish/effect: Metallic.
9. I — Revell 08 Black matt. Required original color legend; see scheme and assembly notes. Candidate: 3G Acrylic NATO Black AK11360. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: AK 3rd Generation water-based acrylic. Finish/effect: Matt.
10. J — Revell 91 Iron metallic. Required original color legend; see scheme and assembly notes. Candidate: 3G Acrylic Dark Aluminium AK11208. Tentative darker metallic candidate. Color and reflected sheen need a dried comparison before use. Paint family: AK 3rd Generation water-based acrylic. Finish/effect: Metallic.
11. K — Revell 78 Tank grey matt. Required original color legend; see scheme and assembly notes. Candidate: Pro Acryl Blue Black 056. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: Pro Acryl water-based acrylic. Finish/effect: Matt.
12. L — Revell 361 Olive green silk matt. Required original color legend; see scheme and assembly notes. No sufficiently close, finish-confirmed single-product olive-green satin candidate is established.
13. M — Revell 67 Greenish grey matt. Required original color legend; see scheme and assembly notes. Candidate: 3G Acrylic Basalt Grey AK11021. Approximate store candidate. Check its dried hue, sheen and any metallic effect against the original before painting. Paint family: AK 3rd Generation water-based acrylic. Finish/effect: Matt.

Original Revell 05650 instructions and kit photographs at Modellversium. This is a retailer/review-hosted original, not an official manufacturer-hosted PDF.
