Construction and optional painting

The original Sumi-ire Pen SHARP is a 0.3 mm mechanical pencil, separate from the liquid marker and brush-pen choices. No current store product is chosen for this optional finishing tool.

Assemble the legs, waist, body, arms and head, then add the Beam Magnum, beam sabers and shield. The included Double Separator helps release the paired parts and disassemble the hands. Nippers are recommended for a cleaner finish even though the wedge gates allow hand removal.

The manual includes a complete finishing tutorial and water-slide decal placement guide. Optional panel lining choices are the GSI Creos Gundam Marker Sumi-ire Pen SHARP, Fine-Point Gundam Markers in Black, Brown and Gray, and Sumi-ire Brush Pens in Black and Gray. It suggests black or gray on white parts and brown or gray on colored parts; these tools are optional.

Keep the four optional paint recipes, including Field Gray (2), whose Japanese name is Olive Gray. Bandai recommends water-based paint and advises against painting ABS parts.

Materials in the parts list: PS parts; ABS H, I, J and other identified frame parts; PE PC-200A polycaps.

Field Gray (2) (English) is paired with Japanese Olive Gray, which has no printed (2) suffix; retain the English numbered distinction.

Optional GSI Fine-Point Gundam Marker Black: The original finishing tutorial names this panel-line option without a product number. No compatible current store item is chosen. Follow the original material warnings; this is separate from the four paint recipes. Reference only; no purchase option is selected.

Optional GSI Fine-Point Gundam Marker Brown: The original finishing tutorial names this panel-line option without a product number. No compatible current store item is chosen. Follow the original material warnings; this is separate from the four paint recipes. Reference only; no purchase option is selected.

Optional GSI Fine-Point Gundam Marker Gray: The original finishing tutorial names this panel-line option without a product number. No compatible current store item is chosen. Follow the original material warnings; this is separate from the four paint recipes. Reference only; no purchase option is selected.

Optional GSI Gundam Marker Brush Pen Black: The original finishing tutorial names this panel-line option without a product number. No compatible current store item is chosen. Follow the original material warnings; this is separate from the four paint recipes. Reference only; no purchase option is selected.

Optional GSI Gundam Marker Brush Pen Gray: The original finishing tutorial names this panel-line option without a product number. No compatible current store item is chosen. Follow the original material warnings; this is separate from the four paint recipes. Reference only; no purchase option is selected.

Optional GSI Sumi-ire Pen SHARP: The original finishing tutorial names this panel-line option without a product number. No compatible current store item is chosen. Follow the original material warnings; this is separate from the four paint recipes. Reference only; no purchase option is selected.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

4 printed roles use 9 distinct named ingredients. 4 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body white: White 100% + Navy Blue small dose.
2. Head yellow: Yellow 45% + White 35% + Orange 20%.
3. Body dark blue: Blue 60% + Cobalt Blue 30% + Black 10%. Candidate recipe incomplete: Cobalt Blue has no chosen store match.
4. Body gray: Gray 85% + Field Gray (2) 10% + Black 5%. Candidate recipe incomplete: Field Gray (2) has no chosen store match.

Named ingredients and optional store candidates

7 mapped purchase cards and 2 disabled ingredient references cover all 9 named ingredients. Mapped cards represent 7 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
2. Navy Blue. Approximate candidate: 3G Acrylic Dark Blue AK11181. Dark Blue has a dark navy-blue chart sample. It is a hue-family approximation, distinct from the near-black Midnight Blue candidate. Family: AK 3rd Generation. Finish/effect: matte.
3. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. Yellow is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
4. Orange. Approximate candidate: 3G Acrylic Medium Orange AK11078. Orange is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
5. Blue. Approximate candidate: 3G Acrylic Deep Blue AK11182. Deep Blue supplies an opaque blue candidate, with untested depth and pigment strength. Family: AK 3rd Generation. Finish/effect: matte.
6. Cobalt Blue. No ordinary opaque Cobalt Blue match is chosen. A metallic paint with the same name would change the effect.
7. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
8. Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. Neutral Grey is a generic gray approximation; it does not define the distinct named Neutral Gray source as an identical formulation. Family: AK 3rd Generation. Finish/effect: matte.
9. Field Gray (2). Numbered Field Gray (2) remains distinct from unnumbered or differently numbered grays; no verified current match is established.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
