Construction and optional painting

Build the Rise of Skywalker X-Wing with its cockpit pilot and R6-D8 astromech, then choose the canopy and landing-gear arrangement and open or closed wings. The SWB-15 display base is included. Choose either the matching stickers or water-slide decals and follow the complete marking plan, including the droid details.

Bandai recommends water-based paint. The nine optional recipes include three pilot colors; the pilot suit keeps its small Flat Base addition. The white-body recipe pairs English Off White with Japanese Grand Prix White, and English IJN Gray with Japanese Light Gray (1). The pilot’s Pale Brown is Japanese Light Brown. No separate droid paint recipe is printed.

Materials in the parts list: PS parts, figures and SWB-15 display base.

Off White (English) / Grand Prix White (Japanese).

IJN Gray (English) / 明灰白色(1), Light Gray (1) or Light Gray White (1) (Japanese). Keep (1) distinct from unnumbered Light Gray and (2).

Pale Brown (English) / 薄茶色, Light Brown (Japanese).

Russet (English) / Azuki color (Japanese).

Tan (English) / Light Brown (Tan), ライトブラウン（タン） (Japanese). Keep it distinct from the pilot-face Light Brown, 薄茶色.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

9 printed roles use 14 distinct named ingredients. 6 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body green: Yellow Green 60% + Green 20% + Tan 20%.
2. Body light green: Yellow Green 50% + White 30% + Green 10% + Tan 10%.
3. Body white: Off White 75% + IJN Gray 25%. Candidate recipe incomplete: IJN Gray has no chosen store match.
4. Body red: Red 100% + Gray small dose.
5. Body silver: Silver 100%.
6. Canopy frame: Silver 100% + Flat Black small dose.
7. Pilot suit: Orange Yellow 70% + Russet 30% + Flat Base small dose. Candidate recipe incomplete: Russet, Flat Base has no chosen store match.
8. Pilot face: Pale Brown 100%. Candidate recipe incomplete: Pale Brown has no chosen store match.
9. Pilot white helmet: White 100%.

Named ingredients and optional store candidates

10 mapped purchase cards and 4 disabled ingredient references cover all 14 named ingredients. Mapped cards represent 10 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. Yellow Green. Approximate candidate: 3G Acrylic Interior Yellow Green AK11138. Interior Yellow Green supplies a yellow-green hue approximation. No aircraft-interior standard is assigned to the source. Family: AK 3rd Generation. Finish/effect: matte.
2. Green. Approximate candidate: 3G Acrylic Deep Green AK11142. Deep Green supplies a generic opaque green approximation, separate from the Dark Green and special named green ingredients. Family: AK 3rd Generation. Finish/effect: matte.
3. Tan. Approximate candidate: 3G Acrylic Tan Earth AK11121. Tan Earth is a tan-brown candidate; original lightness and formulation are not specified. Family: AK 3rd Generation. Finish/effect: matte.
4. White. Approximate candidate: 3G Acrylic White AK11001. White is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
5. Off White. Approximate candidate: 3G Acrylic Offwhite AK11002. Offwhite is an opaque warm off-white candidate supported by the manufacturer chart and current bottle/sample photos. Original undertone and dried match remain untested. Family: AK 3rd Generation. Finish/effect: matte.
6. IJN Gray. IJN Gray has no printed arsenal, standard or code here; no particular Japanese naval gray is assumed.
7. Red. Approximate candidate: 3G Acrylic Matt Red AK11092. Matt Red supplies an opaque red candidate; matte describes the candidate, not a proven source finish. Family: AK 3rd Generation. Finish/effect: matte.
8. Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. Neutral Grey is a generic gray approximation; it does not define the distinct named Neutral Gray source as an identical formulation. Family: AK 3rd Generation. Finish/effect: matte.
9. Silver. Approximate candidate: 3G Acrylic Silver AK11209. Silver is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
10. Flat Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a matte opaque 3GEN paint and preserves the explicitly flat black effect. Candidate pigment strength remains untested. Family: AK 3rd Generation. Finish/effect: matte.
11. Orange Yellow. Approximate candidate: 3G Acrylic Golden Yellow AK11041. Golden Yellow supplies a warm yellow-orange approximation, distinct from Orange and Yellow. Family: AK 3rd Generation. Finish/effect: matte.
12. Russet. The printed Russet ingredient remains distinct from Red brown and Cocoa brown. A matching shade is not established.
13. Flat Base. Original Flat Base is a flattening additive mixed into paint, not a matte color or varnish. No supported equivalent flattening additive with demonstrated mixing behavior is established in the selected family; no finish coat or thinner is substituted.
14. Pale Brown. No defensible Pale Brown match is chosen; warm orange-brown paint is not assumed equivalent.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
