Construction and optional painting

Painting is optional. Follow the binder, booster, stand and mobile-armor conversion steps; preserve moving joints and the fit of removable parts. Use the supplied sticker sheet as shown.

The arms, shins and booster recipe contains Light Blue / Mizu-iro 20%. The joint recipe uses Black 5%. The binder recipe retains separate small amounts of Purple and Indy Blue.

Materials in the parts list: PS; ABS; PE.

The original historical alternative is Gundam Color Green 18. A secondary Mech9 translation says Green 19; the original Green 18 is retained and neither is assigned a modern equivalent. Light Blue / Mizu-iro is retained as printed, without assuming an Aotake or current numbered-paint equivalence.

The original recommends water-based paint and prints legacy Gundam Color alternatives for some complete recipes. Preserve those named and numbered alternatives as shown below. The base recipe ingredients have no printed H/C product numbers; no modern paint-code equivalence is assumed.

Complete original painting recipes

6 printed roles use 13 distinct named ingredients. 5 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. 腕、スネ、ブースター / Arms, shins, booster: Indy Blue 50% + Daytona Green 30% + Light Blue / Mizu-iro (みず色) 20%; OR original Gundam Color Green 18. Candidate recipe incomplete: Indy Blue, Daytona Green, Light Blue / Mizu-iro (みず色) has no chosen store match.
2. バインダー等 / Binders etc.: Cobalt Blue 60% + Navy Blue 25% + Sky Blue 10% + Daytona Green 5% + Purple small amount + Indy Blue small amount; OR original Gundam Color Blue 31. Candidate recipe incomplete: Indy Blue, Daytona Green, Cobalt Blue has no chosen store match.
3. 関節 / Joints: Neutral Gray 95% + Black 5%; OR original Gundam Color Gray 24.
4. 胸部インテーク / Chest intake: Yellow 95% + White 5% + Neutral Gray small amount.
5. 頭部等 / Head etc.: Monza Red 100%. Candidate recipe incomplete: Monza Red has no chosen store match.
6. パイプ / Pipes: Daytona Green 60% + Yellow Green 40%. Candidate recipe incomplete: Daytona Green has no chosen store match.

Named ingredients and optional store candidates

8 mapped purchase cards and 5 disabled ingredient references cover all 13 named ingredients. Mapped cards represent 8 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. Indy Blue. No independently supported water-based Indy Blue hue/formulation is established. A similarly named blue or inferred H/C code is not used.
2. Daytona Green. No independently supported water-based Daytona Green formulation is established. An ordinary green name is insufficient to select a specific candidate.
3. Light Blue / Mizu-iro (みず色). This exact Japanese/English named ingredient has no established current store equivalence. Retained as an unselected source reference; no candidate is chosen by name alone.
4. Cobalt Blue. AK11201 Cobalt Blue is explicitly in the metallic range. The source ordinary Cobalt Blue does not establish a metallic effect, so that candidate is rejected.
5. Navy Blue. Approximate candidate: 3G Acrylic Dark Blue AK11181. Dark Blue has a dark navy-blue chart sample. It is a hue-family approximation, distinct from the near-black Midnight Blue candidate. Family: AK 3rd Generation. Finish/effect: matte.
6. Sky Blue. Approximate candidate: 3G Acrylic Sky Blue AK11175. AK11175 Sky Blue has a light cyan-blue manufacturer-chart and current catalog sample. This is an approximate hue candidate with untested source pigment strength and dried appearance. Family: AK 3rd Generation. Finish/effect: matte.
7. Purple. Approximate candidate: 3G Acrylic Purple AK11073. AK11073 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
8. Neutral Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. The descriptive Neutral Grey candidate supports a neutral-gray approximation. Its bottle may also serve generic Gray while both ingredient names remain separate. Family: AK 3rd Generation. Finish/effect: matte.
9. Black. Approximate candidate: 3G Acrylic Black AK11029. AK11029 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
10. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. AK11044 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
11. White. Approximate candidate: 3G Acrylic White AK11001. AK11001 has a matching opaque color-family sample in the manufacturer chart and current product photos. It is an approximate candidate; source formulation, pigment strength and dried appearance remain untested. Family: AK 3rd Generation. Finish/effect: matte.
12. Monza Red. No independently supported water-based Monza Red candidate is established. Preserve the source name and any bilingual Monza Red / Red Madder note without inventing code equivalence.
13. Yellow Green. Approximate candidate: 3G Acrylic Interior Yellow Green AK11138. Interior Yellow Green supplies a yellow-green hue approximation. No aircraft-interior standard is assigned to the source. Family: AK 3rd Generation. Finish/effect: matte.

Printed legacy alternatives

These 3 references are separate from the ingredient count and are not additional paint requirements.

• Gundam Color Green 18. Original printed alternative for 腕、スネ、ブースター / Arms, shins, booster. It replaces that complete recipe; it is not an extra mixture ingredient. No current equivalent is established.
• Gundam Color Blue 31. Original printed alternative for バインダー等 / Binders etc.. It replaces that complete recipe; it is not an extra mixture ingredient. No current equivalent is established.
• Gundam Color Gray 24. Original printed alternative for 関節 / Joints. It replaces that complete recipe; it is not an extra mixture ingredient. No current equivalent is established.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
