Construction and optional painting

Build Gyunei’s Jagd Doga with the beam assault rifle, shield, beam saber and funnels. The supplied soft clear rods are cut and bent as shown for deployed-funnel poses; the Action Base is sold separately. Use the foil stickers at the marked steps.

The five optional recipes include a Gold 75% and Clear Yellow 25% mixture for the shoulders and shield. Preserve the small Blue addition in the weapon mix. Bandai recommends water-based paint and advises against painting the ABS parts.

Materials in the parts list: PS parts and soft clear funnel-display rods; ABS D and F parts; PE PC-123 polycaps.

Japanese Indy Blue is an uncoded source ingredient; no automatic modern Bright Blue product equivalence.

The original recommends water-based paint and gives named ingredients without numerical H/C product codes. The water-based AK 3GEN store products below are optional approximate candidates, not manufacturer-specified paints or physically verified matches.

Complete original painting recipes

5 printed roles use 11 distinct named ingredients. 4 roles contain mixtures; 0 use separate paint layers. Original proportions describe the source paints. Ratios for these substitute pigments are unvalidated starting points: test and adjust a small dried sample. Unquantified additions remain unquantified. Keep undercoats and topcoats separate and let each layer dry.

1. Body: Daytona Green 50% + Cobalt Blue 45% + Yellow 5%. Candidate recipe incomplete: Daytona Green, Cobalt Blue has no chosen store match.
2. Chest: Cobalt Blue 40% + Midnight Blue 25% + Indy Blue 20% + Black 10% + Blue 5%. Candidate recipe incomplete: Cobalt Blue, Indy Blue has no chosen store match.
3. Shoulders and shield: Gold 75% + Clear Yellow 25%.
4. Weapons: Neutral Gray 90% + Black 10% + Blue small dose.
5. Cockpit hatch: Monza Red 100%. Candidate recipe incomplete: Monza Red has no chosen store match.

Named ingredients and optional store candidates

7 mapped purchase cards and 4 disabled ingredient references cover all 11 named ingredients. Mapped cards represent 7 unique paint variants. Source-role counts are not purchase quantities. Each selected variant is added once, even if chosen for more than one source ingredient.

1. Daytona Green. No independently supported water-based Daytona Green formulation is established. An ordinary green name is insufficient to select a specific candidate.
2. Cobalt Blue. No ordinary opaque Cobalt Blue match is chosen. A metallic paint with the same name would change the effect.
3. Yellow. Approximate candidate: 3G Acrylic Yellow AK11044. Yellow is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
4. Midnight Blue. Approximate candidate: 3G Acrylic Strong Dark Blue AK11187. Strong Dark Blue has a very dark, near-black blue chart sample. It is an approximation to the Midnight Blue hue, distinct from Navy Blue; no manufacturer crosswalk is claimed. Family: AK 3rd Generation. Finish/effect: matte.
5. Indy Blue. No independently supported water-based Indy Blue hue/formulation is established. A similarly named blue or inferred H/C code is not used.
6. Black. Approximate candidate: 3G Acrylic Black AK11029. Black is a named opaque water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: matte.
7. Blue. Approximate candidate: 3G Acrylic Deep Blue AK11182. Deep Blue supplies an opaque blue candidate, with untested depth and pigment strength. Family: AK 3rd Generation. Finish/effect: matte.
8. Gold. Approximate candidate: 3G Acrylic Gold AK11191. Gold is a named metallic water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: metallic.
9. Clear Yellow. Approximate candidate: 3G Acrylic Clear Yellow AK11217. Clear Yellow is a named transparent water-based candidate. Exact source formulation and dried appearance are untested. Family: AK 3rd Generation. Finish/effect: transparent.
10. Neutral Gray. Approximate candidate: 3G Acrylic Neutral Grey AK11018. The descriptive Neutral Grey candidate supports a neutral-gray approximation. Its bottle may also serve generic Gray while both ingredient names remain separate. Family: AK 3rd Generation. Finish/effect: matte.
11. Monza Red. No independently supported water-based Monza Red candidate is established. Preserve the source name and any bilingual Monza Red / Red Madder note without inventing code equivalence.

Optional supplies are recommendations for the tasks described above, not manufacturer-required purchases. The AK 3GEN thinner applies only to the AK 3GEN candidates. Do not paint materials the original warns against painting. Digital color squares are browsing aids; they do not prove dried color, pigment strength, sheen, metallic reflection, transparency or a successful mixture.
